Dit display komt overeen met de Nokia 5110 norm waardoor het prima geschikt is om gegevens of grafieken van meetwaarden weer te geven via een microcontroller of een single-board computer. Bovendien is het display compatibel met alle Raspberry Pi, Arduino, CubieBoard, Banana Pi en microcontroller zonder extra handelingen. Specificaties Chipset Philips PCD8544 Interface SPI Resolutie 84 x 48 Pixels Voeding 2.7-3.3 V Speciale kenmerken Backlight Compatibel met Raspberry Pi, Arduino, CubieBoard, Banana Pi en microcontroller Afmetingen 45 x 45 x 14 mm Gewicht 14 g

Lees meer minder

De M12-mountlens (5 MP, 25 mm) is ideaal voor gebruik met de Raspberry Pi HQ Cameramodule en levert scherpe, gedetailleerde beelden voor uiteenlopende toepassingen.

Lees meer minder

If you are searching for a possibility to keep your Raspberry Pi cool, than this mini fan is the perfect possibility for this. The active cooler is ready to use right after pluging in the two GPIO pins into the 5V and GND GPI-O port. The cooler is compatible to all Raspberry Pis and is perfect to keep them cool, even under full load. Voltage: 5 V Current: 0.2 A Dimensions: 30 x 30 x 7 mm

Lees meer minder

With a 6x20 grid of 2.54 mm spaced holes for easy soldering and labelled Pico pins so you know what's what, Pico Proto is perfect for when you're happy with your breadboard project and want to give it a secure, smart and compact long-term home. Pico Proto doesn't come with any headers attached, so you will need to either solder it directly to your Pico's male header pins (for a permanent, but super slim sandwich) or solder it to some female header. Features 40 2.54 mm spaced holes for attaching to your Pico. 120 2.54 mm spaced holes (6x20 grid) for attaching other things Compatible with Raspberry Pi Pico. Dimensions: approx 51 x 25 x 1 mm (L x W x H)

Lees meer minder

The Maker pHAT is the solution to the most common problems beginners face starting with Raspberry PI. Its intelligent and simple design makes it easy to attach to your Pi, and it helps you avoid all the tedious work of connection various other accessories. Additionally, the LEDs corresponding to each pin makes it extremely easy to see where a potential problem lies The Maker pHat has the same size as the Raspberry Pi Zero with all 4mounting holes aligned. However, it can be used with Raspberry Pi 3B, 3B+ and 3A+, by inserting a 2 x 20 stacking header. Features Raspberry Pi Zero size, stack perfectly on to Raspberry Pi Zero Compatible with standard size Raspberry Pi 3B / 3B+, medium size Raspberry Pi 3A+ and smaller size Raspberry Pi Zero / W / WH. Standard Raspberry Pi GPIO footprint. LED array for selected GPIO pins (GPIO 17, 18, 27, 22, 25, 12, 13, 19). 3x on board programmable push buttons (GPIO 21, 19 and 20, need to configure as input pull up). Onboard active buzzer (GPIO 26). Proper labels for all GPIOs, including SPI, UART, I2C, 5V, 3.3V, and GND. Utilize USB Micro-B socket for 5V input and USB to UART communication. USB serial facilitated by the FT231X Input voltage: USB 5 V, from a computer, power bank or a standard USB adapter. Mount on Raspberry Pi Zero Mount on Raspberry Pi 3B, 3B+ and 3A+

Lees meer minder

Specifications CM4 socket Suitable for all variants of Compute Module 4 Networking Gigabit Ethernet RJ45 connectorM.2 M KEY, supports communication modules or NVME SSD Connector Raspberry Pi 40-PIN GPIO header USB 2x USB 2.0 Type A2x USB 2.0 via FFC connector Display MIPI DSI display port (15-pin 1.0 mm FPC connector) Camera 2x MIPI CSI-2 camera port (15-pin 1.0 mm FPC connector) Video 2x HDMI port (including one port via FFC connector), supports 4K 30fps output RTC N/A Storage MicroSD card socket for Compute Module 4 Lite (without eMMC) variants Fan header No fan control, 5 V Power input 5 V Dimensions 85 x 56 mm Included 1x CM4-IO-BASE-A 1x SSD mounting screw Downloads Wiki

Lees meer minder

The Speaker Kit for Raspberry Pi is a small amplified speaker designed for the Raspberry Pi. Included MonkMakes Amplified Speaker Set of 10 female to female header wires Short stereo audio lead Raspberry Leaf GPIO template Downloads Instructions Datasheet

Lees meer minder

De Raspberry Pi Monitor is een 15,6-inch Full HD-computerscherm. Gebruiksvriendelijk, veelzijdig, compact en betaalbaar, het is de perfecte desktop-displaygenoot voor zowel Raspberry Pi-computers als andere apparaten. Met ingebouwde audio via twee naar voren gerichte luidsprekers, VESA- en schroefmontagemogelijkheden en een geïntegreerde in hoek verstelbare standaard is de Raspberry Pi Monitor ideaal voor desktopgebruik of voor integratie in projecten en systemen. Hij kan rechtstreeks van een Raspberry Pi worden voorzien, of via een aparte voeding. Kenmerken 15,6-inch Full HD 1080p IPS-scherm Geïntegreerde in hoek verstelbare standaard Ingebouwde audio via twee naar voren gerichte luidsprekers Audio-uitgang via 3,5 mm-aansluiting HDMI-ingang op volledige grootte VESA- en schroefmontageopties Volume- en helderheidsknoppen USB-C-voedingskabel Specificaties Display Schermgrootte: 15,6 inch, verhouding 16:9 Paneeltype: IPS LCD met antireflectiecoating Weergaveresolutie: 1920 x 1080 Kleurdiepte: 16,2M Helderheid (typisch): 250 nits Kleurgamma: 45% Kijkhoek: 80° Voeding 1,5 A/5 V Kan rechtstreeks worden gevoed via een Raspberry Pi USB poort (max 60% helderheid, 50% volume) of via een aparte voeding (max 100% helderheid, 100% volume) Connectiviteit Standaard HDMI-poort (compatibel met 1.4) 3,5 mm stereohoofdtelefoonaansluiting USB-C (voeding in) Audio 2x 1,2 W geïntegreerde luidsprekers Ondersteuning voor bemonsteringsfrequenties van 44,1 kHz, 48 kHz en 96 kHz Downloads Datasheet

Lees meer minder

The DiP-Pi PIoT is an Advanced Powered, WiFi connectivity System with sensors embedded interfaces that cover most of possible needs for IoT application based on Raspberry Pi Pico. It can supply the system with up to 1.5 A @ 4.8 V delivered from 6-18 VDC on various powering schemes like Cars, Industrial plant etc., additionally to original micro-USB of the Raspberry Pi Pico. It supports LiPo or Li-Ion Battery with Automatic Charger as also automatic switching from cable powering to battery powering or reverse (UPS functionality) when cable powering lost. Extended Powering Source (EPR) is protected with PPTC Resettable fuse, Reverse Polarity, as also ESD.The DiP-Pi PIoT contains Raspberry Pi Pico embedded RESET button as also ON/OFF Slide Switch that is acting on all powering sources (USB, EPR or Battery). User can monitor (via Raspberry Pi Pico A/D pins) battery level and EPR Level with PICO’s A/D converters. Both A/D inputs are bridged with 0402 resistors (0 OHM) therefore if for any reason user needs to use those Pico pins for their own application can be easy removed. The charger is automatically charging connected battery (if used) but in addition user can switch charger ON/OFF if their application needs it.DiP-Pi PIoT can be used for cable powered IoT systems, but also for pure Battery Powered System with ON/OFF. Each powering source status is indicated by separate informative LEDs (VBUS, VSYS, VEPR, CHGR, V3V3).User can use any capacity of LiPo or Li-Ion type; however, must take care to use PCB protected batteries with max discharge current allowed of 2 A. The embedded battery charger is set to charge battery with 240 mA current. This current is set by resistor so if user need more/less can himself to change it. The DiP-Pi PIoT is also equipped with WiFi ESP8266 Clone module with embedded antenna. This feature open a wide range of IoT applications based on it.In Addition to all above features DiP-Pi PIoT is equipped with embedded 1-wire, DHT11/22 sensors, and micro–SD Card interfaces. Combination of the extended powering, battery, and sensors interfaces make the DiP-Pi PIoT ideal for IoT applications like data logger, plants monitoring, refrigerators monitoring etc.DiP-Pi PIoT is supported with plenty of ready to use examples written in Micro Python or C/C++.SpecificationsGeneral Dimensions 21 x 51 mm Raspberry Pi Pico pinout compatible Independent Informative LEDs (VBUS, VSYS, VEPR, CHGR, V3V3) Raspberry Pi Pico RESET Button ON/OFF Slide Switch acting on all powering sources (USB, EPR, Battery) External Powering 6-18 VDC (Cars, Industrial Applications etc.) External Power (6-18 VDC) Level Monitoring Battery Level Monitoring Inverse Polarity Protection PPTC Fuse Protection ESD Protection Automatic Battery Charger (for PCB protected LiPo, Li-Ion – 2 A Max) Automatic/User Control Automatic Switch from Cable Powering to Battery Powering and reverse (UPS Functionality) Various powering schemes can be used at the same time with USB Powering, External Powering and Battery Powering 1.5 A @ 4.8 V Buck Converter on EPR Embedded 3.3 V @ 600 mA LDO ESP8266 Clone WiFi Connectivity ESP8266 Firmware Upload Switch Embedded 1-wire Interface Embedded DHT-11/22 Interface Powering Options Raspberry Pi Pico micro-USB (via VBUS) External Powering 6-18 V (via dedicated Socket – 3.4/1.3 mm) External Battery Supported Battery Types LiPo with protection PCB max current 2A Li-Ion with protection PCB max current 2A Embedded Peripherals and Interfaces Embedded 1-wire interface Embedded DHT-11/22 Interface Micro SD Card Socket Programmer Interface Standard Raspberry Pi Pico C/C++ Standard Raspberry Pi Pico Micro Python Case CompatibilityDiP-Pi Plexi-Cut CaseSystem Monitoring Battery Level via Raspberry Pi Pico ADC0 (GP26) EPR Level via Raspberry Pi Pico ADC1 (GP27) Informative LEDs VB (VUSB) VS (VSYS) VE (VEPR) CH (VCHR) V3 (V3V3) System Protection Direct Raspberry Pi Pico Hardware Reset Button ESD Protection on EPR Reverse Polarity Protection on EPR PPTC 500 mA @ 18 V fuse on EPR EPR/LDO Over Temperature protection EPR/LDO Over Current protection System Design Designed and Simulated with PDA Analyzer with one of the most advanced CAD/CAM Tools – Altium Designer Industrial Originated PCB Construction 2 ozcopper PCB manufactured for proper high current supply and cooling 6 mils track/6 mils gap technology 2 layers PCB PCB Surface Finishing – Immersion Gold Multi-layer Copper Thermal Pipes for increased System Thermal Response and better passive cooling Downloads Datasheet Manual

Lees meer minder

This is an I/O expansion kit designed for Raspberry Pi, which provides 5 sets of 2x20 pinheaders, that means a handy way to 'stack' multi different HATs together, and use them as a specific combination / project. Features Standard Raspberry Pi connectivity, directly pluggable OR through ribbon cable 5 sets of 2x20 pinheaders, connect multi HATs together USB external power port, provides enough power supply for multi HATs Clear and descriptive pin labels for easy use Reserved jumper pads on the bottom side, pin connections are changeable by soldering, to avoid pin conflicts Note: make sure there are no any pin conflicts between the HATs you want to use together before connecting. Specifications Dimensions: 183 × 65 mm Mounting hole size: 3 mm Included 1x Stack HAT 1x Ribbon cable 40-Pin 1x 2x20 male pinheader 1x RPi screws pack (4pcs) x1

Lees meer minder

Je zou Pirate Audio Headphone Amp kunnen gebruiken om een nette, zakformaat speler te bouwen voor lokale audiobestanden (MP3, FLAC, etc) of voor het streamen van muziek van online diensten zoals Spotify. Om je op weg te helpen heeft Pimoroni plugins gebouwd voor Mopidy waarmee je prachtige album art kunt weergeven, je tracks kunt afspelen/pauzeren en het volume kunt regelen. De DAC en hoofdtelefoonversterker geven je heldere digitaal versterkte audio via je hoofdtelefoon met kabel. Pirate Audio is een reeks van alles-in-een audio boards voor Raspberry Pi, met hoge kwaliteit digitale audio, prachtig heldere IPS displays voor album art, tactiele knoppen voor playback controle, en een aangepaste Pirate Audio software en installer om het opzetten van dit allemaal een fluitje van een cent te maken.Functies Versterkte digitale audio (24-bit / 192KHz) over I2S PAM8908 hoofdtelefoonversterker chip Low-gain / high-gain schakelaar (high-gain verhoogt met 12dB) PCM5100A DAC-chip 3.5mm stereo aansluiting 1,3' IPS-kleurenscherm (240x240px) (ST7789 driver) Vier tactiele knoppen Mini HAT-formaat bord Volledig gemonteerd Compatibel met alle 40-pin header Raspberry Pi modellen Afmetingen: 65x30.5x9.5mm SoftwareDe Pirate Audio software en installer installeert de Python bibliotheek voor de LCD, configureert de I2S audio en SPI, en installeert vervolgens Mopidy en de aangepaste Pirate Audio plugins om album art en track info weer te geven, en om de knoppen te gebruiken voor playback control.Hier ziet u hoe u aan de slag kunt: Stel een SD-kaart in met de laatste versie van Raspberry Pi OS. Gebonden met Wi-Fi of een bekabeld netwerk. Open een terminal en typ het volgende:git clone https://github.com/pimoroni/pirate-audiocd pirate-audio/mopidysudo ./install.sh Reboot uw Pi Downloads PAM8908 Datasheet PCM5100A-gegevensblad Pirate Audio software

Lees meer minder

This PCIe to M.2 adapter is specifically designed for the Raspberry Pi 5. It supports the NVMe protocol for M.2 SSDs, enabling fast read and write operations, and adheres to the HAT+ standard. The adapter is compatible with M.2 SSDs in the 2230 and 2242 sizes. Inbegrepen 1x PCIe to M.2 HAT+ Adapter 1x 2x20 Pin header 1x 16P cable (40 mm) 1x Standoff pack Downloads Wiki

Lees meer minder

The Picon Zero is an add-on for the Raspberry Pi. It has the same size as a Raspberry Pi Zero, making it ideal to function as a pHat. Of course, it can be used on any other Raspberry Pi via a 40-pin GPIO connector.As well as two full H-Bridge motor drivers, the Picon Zero has several Input/Output pins giving you multiple configuration options. That allows you to easily add outputs or analog inputs to your Raspberry Pi without any complicated software or kernel-specific drivers. At the same time, it opens up 5 GPIO pins from the Raspberry Pi, and it provides the interface for an HC-SR04 ultrasonic distance sensor.The Picon Zero comes with all components, including the headers and screw terminals, fully soldered. Soldering isn't required. You can use it right out of the box.Features pHat format PCB: 65 mm x 30 mm Two full H-Bridge motor drivers. Drive up to 1.5 A continuously per channel, at 3 V - 11 V. Each motor output has both a 2-pin male header and a 2-pin screw terminal. The motors can be powered from the Picon Zero's 5 V or an external power source (3 V - 11 V). The Picon Zero's 5 V can be selected to be from the Raspberry Pi's 5 V line, or a USB connector on the Picon Zero. That means that you can effectively have 2 USB battery banks: one to power the servos and motors on the Picon Zero and the other to power the Pi. 4 Inputs that can accept up to 5 V. These inputs can be configured as follows: Digital inputs Analog inputs DS18B20 DHT11 6 Outputs that can drive 5 V and be configured as: Digital Output PWM Output Servo NeoPixel WS2812 All Inputs and Outputs use GVS 3-pin male headers. 4-pin female header that connects directly to an HC-SR04 ultrasonic distance sensor. 8-pin female header for Ground, 3.3 V, 5 V, and 5 GPIO signals allowing you to add their additional features. Hardware ConfigurationPicon Zero has two jumpers for setting the hardware configuration. Ensure that you have placed them in the correct position. JP1 – Board 5 V Selector. This jumper selects where to get the 5 V power from for the Picon Zero Outputs. The options are: Jumper at the top between RPI and 5 V. The 5 V power for the board is taken from the Raspberry Pi pins on the GPIO connector. Because of the low power output devices and the 5 V motors, all devices can be powered with a single 5 V power input. Jumper at the bottom between USB and 5 V. The 5 V power is taken from the microUSB connector on the Picon Zero. Useful for higher power output devices, since you can provide extra power through the micro-USB connector on the board JP2 – Motor Power Selector. This jumper selects where the motors get the power. The two options here are the following: Jumper at the top between MotorPower and Vin. The motors are driven via the 2-pin screw terminal. The voltage can be between 3 V and 11 V. Useful for motors that require a voltage different from 5 V, or that require more current than is available on either of the USB input connectors Jumper at the bottom between 5 V and MotorPower. The motors are driven from the board's 5 V. Raspberry Pi ConfigurationThe Picon Zero is an I²C device. Make sure your Raspberry Pi is set up correctly to use I²C and SMBus: sudo apt-get install python-smbus python3-smbus python-dev python3-dev sudo nano /boot/config.txt Add the following lines at the end of the file dtparam=i2c1=on dtparam=i2c_arm=on Press Ctrl-X and use the default prompts to save sudo reboot Plugin the Picon Zero onto the Pi and run i2cdetect -y 1If everything goes well, you will see the Picon Zero showing up as address 22 as shown below:

Lees meer minder

De M12-mountlens (12 MP, 8 mm) is ideaal voor gebruik met de Raspberry Pi HQ Cameramodule en levert scherpe, gedetailleerde beelden voor uiteenlopende toepassingen.

Lees meer minder

Features Compatible with Raspberry Pi 4 only Cutout in lid for 40x30mm heatsink or Fan SHIM Super-slimline profile Fully HAT-compatible Protects your beloved Pi Clear top and base leave Raspberry Pi 4 visible GPIO cut-out Handy laser-etched port labels Leaves all ports accessible Made from lightweight, high-quality, cast acrylic Great for hacking and tinkering! Made in Sheffield, UK Weighing just over 50 grams, the case is lightweight and ideal for mounting to any surface. No tools are required for assembly or disassembly. The dimensions are: 99 × 66 × 15 mm. In the video below you can see a quick assembly guide.

Lees meer minder

SHIM is een oude Yorkshire term die 'Shove Hardware In Middle' betekent - wij gebruiken het voor Raspberry Pi add-ons die zijn ontworpen om tussen uw Pi en een HAT of mini HAT te worden geklemd. Deze heeft een slimme friction fit header die gemakkelijk over je GPIO pinnen glijdt, niet gesoldeerd hoeft te worden*, en gemakkelijk te verwijderen is.De MAX98357A gecombineerde DAC/versterker-chip neemt digitale audio van hoge kwaliteit van uw Pi en versterkt deze, zodat deze kan worden gebruikt met een luidspreker zonder voeding. De push-fit connectors maken het eenvoudig om uw luidspreker aan te sluiten, of het nu een boekenplank of vloerstaande luidspreker is, de luidspreker in een oude radio, of een andere luidspreker die u misschien heeft liggen. Omdat Audio Amp SHIM geen extra ruimte toevoegt aan uw Pi, is het perfect om in te bouwen in een compacte behuizing - u kunt het gebruiken om een kleine MP3-speler te maken om lokale bestanden af te spelen of te streamen van diensten zoals Spotify, een vintage radio de mogelijkheid te geven om digitale radiostreams af te spelen of bliepgeluiden te integreren in uw eigen retro handheld. Het is ook een handige manier om audio-uitgang aan uw Pi Zero of Pi 400 toe te voegen!Let op: Raspberry Pi and speakers zijn niet inbegrepen bij dit board. Features MAX98357A DAC / amplifier chip Mono 3W audio out Push-fit speaker terminals SHIM-format board with friction-fit connectors 2x mounting holes (M2.5) for if you want to secure everything together with bolts Fully-assembled No soldering required (*unless you're using a Pi that comes without a header) Compatible with all 40-pin header Raspberry Pi models SoftwareDe eenvoudigste manier om alles in te stellen is gebruik te maken van Pimoroni's Pirate Audio software en installer die I2S audio configureert, alsook Mopidy installeert en onze aangepaste Pirate Audio plugins waarmee u Spotify kunt streamen en lokale bestanden kunt afspelen.Hier is hoe te beginnen: Stel een SD-kaart in met de laatste versie van Raspberry Pi OS. Maak verbinding met Wi-Fi of een bekabeld netwerk. Open een terminal en type het volgende:git clone https://github.com/pimoroni/pirate-audiocd pirate-audio/mopidysudo ./install.sh Reboot your Pi Downloads MAX98357A Datasheet Pirate Audio software Schematic

Lees meer minder

This board is an all-digital conversion of Raspberry Pi's VGA reference design, great for if you want to start hacking on video and/or audio output from a Raspberry Pi Pico and piping it straight into a modern monitor.Features HDMI connector PCM5100A DAC for line out audio over I²S (datasheet) SD card slot Reset button Socket headers to install your Raspberry Pi Pico Three user-controllable switches Rubber feet Compatible with Raspberry Pi Pico No soldering required (as long as your Pico has header pins attached) Programmable with C/C++ Note: Raspberry Pi Pico is not included. Your Pico will need to have pin headers soldered to it (with the pins pointing downwards) to attach to our add-on boards.Downloads Schematic GitHub

Lees meer minder

Turn your Raspberry Pi into a retro games console! Picade X HAT includes joystick and button inputs, a 3 W I²S DAC/amplifier, and soft power switch. This HAT has all the same great features as the original Picade HAT but now has no-fuss female Dupont connectors to hook up your joystick and buttons. Simply pop Picade X HAT onto your Pi, plug a USB-C power supply into the connector on the HAT (it back-powers your Pi through the GPIO, so no need for a separate power supply), wire up your controls, and install the driver! It's ideal for your own DIY arcade cabinet builds, or for interfaces that need big, colourful buttons and sound. Features I²S audio DAC with 3 W amplifier (mono) and push-fit terminals Safe power on/off system with tactile power button and LED USB-C connector for power (back-powers your Pi) 4-way digital joystick inputs 6x player button inputs 4x utility button inputs 1x soft power switch input 1x power LED output Plasma button connector Breakout pins for power, I²C, and 2 additional buttons Picade X HAT pinout Compatible with all 40-pin Raspberry Pi models The I²S DAC blends both channels of digital audio from the Raspberry Pi into a single mono output. This is then passed through a 3 W amplifier to power a connected speaker. The board also features a soft power switch that allows you turn your Pi on and off safely without risk of SD card corruption. Tap the connected button to start up, and press and hold it for 3 seconds to fully shutdown and disconnect power. Software/Installation Open a terminal and type curl https://get.pimoroni.com/picadehat | bash to run the installer. You'll need to reboot once the installation is complete, if it doesn't prompt you to do so. The software does not support Raspbian Wheezy Notes With USB-C power connected through Picade X HAT you'll need either to tap the connected power button or the button marked 'switch' on the HAT to power on your Pi.

Lees meer minder

Take control of and monitor your world with our ultimate jack-of-all-trades Raspberry Pi HAT!We've pulled together a great set of features into this home monitoring and automation controller. With relays, analog channels, powered outputs, and buffered inputs (all 24 V tolerant) you can now hook up a plethora of goodies to your Raspberry Pi all at once.Better still each channel has an indicator LEDs which means at a glance you can see what's happening with your setup. Even the analog channels have dimming LEDs that allow you to see the value they are currently sensing – swish!Ideal for smart home and automation projects, giving your greenhouse intelligent sprinklers, or scheduling your fish feeding!Features 3x 24 V @ 2 A relays (NC and NO terminals) 3x 12-bit ADC @ 0-24 V (±2% accuracy) 3x 24 V tolerant buffered inputs 3x 24 V tolerant sinking outputs 15x channel indicator LEDs 1x 12-bit ADC @ 0-3.3 V 3.5 mm screw terminals Power, Comms, and Warn! LED indicators SPI, TX (#14), RX (#15), #25 pins broken out Automation HAT pinout Compatible with all 40-pin header Raspberry Pi models Python library Schematic Comes fully assembled (broken out pins require soldering) SoftwareAs ever, we've made a super-simple to use Python library to take advantage of Automation HAT's multitudinous functions, with examples to get you started.Our input, output and relay examples show you how to read the analog and digital inputs, switch the outputs on and off, and control the relays.Notes We recommend you use a set of brass M2.5 standoffs with Automation HAT to avoid pins contacting the HDMI port if the HAT is pushed down Loads for the buffered outputs should be switched on the ground side, i.e. 12/24 V (from supply) -> load -> output terminal -> ground (from supply) The relays can tolerate up to 2 A each and should be switched on the high side The sinking outputs can sink a maximum 500 mA total across the 3 outputs, so if you use a single channel you can sink the whole 500 mA across it. The accuracy of the ADC is ±2%. Do not use to switch mains voltages!
