Unitree Go1 series consists of quadruped robots for the research & development of autonomous systems in the fields of human-robot interaction (HRI), SLAM & transportation. Due to the four legs, as well as the 12DOF, this robot can handle a variety of different terrains. The Go1 comes with a perfected drive & power management system, which enables a speed (depending on the version) of up to 3.7 m/s or 11.88 km/h with an operating time of up to 2.5 hours. Furthermore, the motors have a torque of 23.70N.m at the body/thighs and 35.55N.m at the knees, which also allow jumps or backflips.Features High Dynamics 17 km/h Intelligent Side-Follow System (ISS) Super Sensory System (SSS) 10-view Detection AI Detection, Human Recognition, etc. Flexible and adaptive Joints Long Endurance Specifications Light and Compact Weight: 12 kg Size (folded): 0.588 x 0.29 x 0.22 m High Performance Max Speed: 4.7 m/s (17 kmh or 10.6 mph) Intelligent Side Follow System (Adopt Patented Wireless Vector Positioning and Control Technology) Robot dog can walk alongside its owner and not only follow The human-machine interaction is both harmonious and safe Super Sensory System Full View Coverage 5 Sets Fish-Eye Stereo Depth Cameras + AI Post-processing + 3 Sets of Hypersonic Sensors Lens Angle: 150 x 170° Built-in Powerful AI 16-core CPU + GPU (384 Cores, 1.5 TFLOPS) ISS and SSS Function Cooperatively Strong & Reliable Power System New Power Joint with Super Lightweight Low Noise and Long Life Heat Pipe Cooling System Built in the Knee Joint Motor Body/thigh joints: C1-8: 520 g 23.70N.m Knee Joint: C1-8 x 1.5 ratio 35.55N.m Unitree Go1 Variants: Go1 Air, Go1 Pro, Go1 EduThe Go1 series has 3 variants (Go1 Air, Go1 Pro and Go1 Edu), which differ a little technically. The differences are mainly the processors and sensor systems, the Air and Pro variant works, depending on the model, with one or 3x (4x 1.43 GHz 128 Cores 0.5 T) processor as well as with 1 or 5 super sensor systems. Both variants are equipped with 3 ultrasonic sensors. The Go1 Edu variant has up to 3 nano processors, 5 super sensor systems, and 4 ultrasonic sensors.Air vs Pro vs Edu Go1 Air Go1 Pro Go1 Edu SSS 1 Super-sensing system 1 set 5 sets 5 sets Sensing calculation 1x (4x 1.43 GHz 128 Cores 0.5 T) 3x (4x 1.43 GHz 128 Cores 0.5 T) 2 Nano + (1 Nano or 1 NX) ISS 1 Intelligent Concomitant ✓ ✓ ✓ RTT 1 Pictures Transaction ✓ ✓ ✓ Charger 24 V, 4 V 24 V, 6 V 24 V, 6 V Remote Control ✓ ✓ ✓ Load ≈3 kg ≈3 kg ≈5 kg (max ~10 kg) Heat Pipe Assisted Heat Dissipation ✓ ✓ ✓ Motion Speed 0~2.5 m/s 0~3.5 m/s 0~3.7 m/s (max ~5 m/s) Battery 1x 1x 1x Graphical Programming Interface ✓ ✓ ✓ Scientific Programming Interface ✓ Python Programming Interface ✓ HAI 1 Human Sensing ✓ APP Top View ✓ ✓ 4G ✓ Foot-end Physical Force Sensor ✓ Multifunctional Peripheral Expansion Interface ✓ Radar 2D or 3D optional Included 1x Unitree Go1 1x Unitree Go1 Battery 1x Unitree Go1 Charger 1x Unitree Go1 Remote Controller Downloads User Manual GitHub

Lees meer minder

Finer tolerance, higher speedIn the development of SV2, we focused on providing finer tolerance, higher speed and larger build area, including 8 mil (200 micron) traces More than 2 layers Finer glue dispensing with Single-part Epoxy An Assembly System supporting 100+ parts as small as 0402, loaded in SMT strips 6' x 6' (150 x 150 mm) working area Interact with SV2 through a web browser, uploading standard Gerber files, image files and centroid-and-rotation files to print and assemble your boards in minutes!Inkjet Printing New inkjet system, featuring more than 300 nozzles and a much smaller droplet size, allowing for thinner lines Larger ink capacity for more boards per cartridge Cleaning station to automatically maintain nozzles and extend cartridge life-span Wider printhead, allowing for an increased sweep across the substrate and faster printing Dispense Finer Compatible with single-part epoxy New motor, gearing and encoder allows for finer control in dispensing process Micro-dispensing tips Cleaning station for automated tip-wiping BotFactory has a vision to revolutionize the electronics industry by bringing the factory to the desktop, creating a world where engineers, researchers and students can prototype printed electronics right there and then. BotFactory SV2 is their latest generation, capable of printing multilayer circuits, dispensing paste and pick-and-placing components within a small, 50 x 50 cm footprint.BotFactory fabricates and assembles printed circuit boards in a way radically different from the familiar, stencil-andetch methods. The conductive traces are printed using a conductive, nanoparticle silver ink onto a substrate (FR-4 or even flexible Kapton®), and then a polymer ink is printed over the traces. Vias are printed using an additive process from the bottom to the top of the board. As CTO and Founder Carlos Ospina explains, “People always ask us ‘how can you create a multilayer circuit without drilling?!’, but at BotFactory we know that drilling is just one of many possible ways to connect a top layer to a bottom one”.Each BotFactory SV2 comes with three heads to perform the printing, dispensing and assembly process. After printing the traces, the printing head is swapped out for the dispensing head and conductive glue deposited onto the pads. The final step is assembly where a pickand-place head equipped with a vacuum pump picks up parts from a tape-strip holder and use an upwards-facing camera to align the part and place it in the correct spot.BotFactory took many lessons from their first product, Squink, and integrated them into SV2. The primary focus was on the printing technology, leveraging new inkjetting methods and curing techniques to print finer conductive traces, thinner insulating ink layers and overall speed. SV2 will be able to print more than two layers with an estimated trace width of 200 microns. Of course, with thinner lines comes finer dispensing, which required a major change to dispensing along with the conductive glues utilized; SV2 will now include a one-part epoxy instead of a two-part as with Squink. Pick-and-place supports 10 times more parts, along with tape-strip packaging and 0402-sized components, allowing users to explore small-batch production from within their workshop.

Lees meer minder

The X-Carve CNC machine is great for Makers looking to start their CNC journey. Reliable, customizable, and expandable: X-Carve is also the best-selling machine for entrepreneurs and small businesses.Start producing, no CNC knowledge required. X-Carve and Easel simplify 3D carving so you can begin working with wood, plastics and other materials in minutes.Features Carves wood, plastics, and materials like aluminum, Corian®️, and linoleum up to 37 inches wide. Easy-to-follow assembly instructions will help familiarize you with your machine. This model V2 is 3x faster, more rigid, and more accurate than the original X-Carve. Design -> Carve -> Sell Design: Sketch out your own idea and upload to Easel software, or browse from the library of over 3 million designs. Carve: Easel controls the spindle and makes calculations so there's no guesswork. Sell: X-Carve + Easel speeds up production so you can take on more jobs and get them out faster. The bundle pays for itself in no time. Carvable Materials Wood/Wood Composites: Hardwoods, softwoods, MDF, plywoods, etc. Plastics: HDPE, Delrin®️, polycarbonate, acrylic, Corian®️, etc. Non-Ferrous Metals: Aluminum, brass, copper, etc. Import File Types: G-Code, SVG, or DXF files from any software Software Compatible with standard g-code and GRBL 1 Year of Easel Pro Included (world’s easiest CAD/CAM software) Size & Weight Work Area: 750 x 750 x 114 mm (29.5 x 29.5 x 4.5') Machine Footprint: 1041 x 1321 x 559 mm (41 x 52 x 22') Maximum Passthrough Sheet Width: 940 mm (37') Finish: Anodized Aluminum Product Weight: 45 kg Shipping Weight: 50 kg Included X-Carve Base & Hardware Rail Kit DeWalt 26200 Spindle X-Controller Kit Nema 23 Motors Kit Waste Board Drag Chain Toolkit Homing Kit Z-Probe Kit Side Board Dust Control System Clamp Set Digital Calipers 1 Year Easel Pro Software Downloads Instructions Support 3D Models and Drawings

Lees meer minder

Soldeerpasta doseren en reflowen in éénDe Voltera V-One maakt dubbellaags prototype printplaten op uw eigen bureau. Gerber-bestanden gaan erin, geprinte printplaten komen eruit. De dispenser legt een zilver-gebaseerde geleidende inkt om uw schakeling ter plekke te printen. Het assembleren van printplaten is eenvoudig met de V-One's soldeerpasta verdeler en reflow functies. Plaats uw printplaat op het printbed en importeer uw Gerber-bestand in Voltera's software.Geen stencils meer nodigVoltera's software is ontworpen om gemakkelijk mee uit de voeten te kunnen. Vanaf het importeren van uw Gerber-bestanden tot het moment dat u op print drukt, leidt de software u veilig door elke stap.Compatibel met EAGLE, Altium, KiCad, Mentor Graphics, Cadence, DipTrace, Upverter.De V-One Desktop PCB Printer wordt geleverd met alle accessoires en benodigdheden die nodig zijn om aan de slag te gaan:In de verpakking 1 Conductor 2 cartridge 1 Solder Paste cartridge 10 2'x3' FR4 substrates 6 3'x4' FR4 substrates 10 2'x3' FR1 substrates 6 3'x4' FR1 substrates 25 disposable 230 micron nozzles 1 Burnishing pad 1 Solder wire spool 1 Drill bit set 200 0.4 mm rivets 200 1.0 mm rivets 2 Rivet tools 1 Sacrificial layer 1 Hello World starter kit 1 Punk Console starter kit Accessories 2 Substrate clamps and thumbscrews 2 Dispensers with caps 1 Probe 1 Drill 1 Set of safety glasses 1 Voltera anti-static tweezers Downloads Specifications V-One Software User manuals Safety datasheets Technical datasheets Voltera CAM file for EAGLE Substrates and templates Meer Info Frequently Asked Questions More from the Voltera community Technische Specificaties Printspecificaties Minimum trace width 0.2 mm Minimum passive size 1005 Minimum pin-to-pin pitch (conductive ink) 0.8 mml Minimum pin-to-pin pitch (solder paste) 0.5 mml Resistivity 12 mΩ/sq @ 70 um height Substrate material FR4 Maximum board thickness 3 mm Soldeerspecificaties Solder paste alloy Sn42/Bi57.6/Ag0.4 Solder wire alloy SnBiAg1 Soldering iron temperature 180-210°C Drukbed Print area 135 x 113.5 mm Max. heated bed temperature 240°C Heated bed ramp rate ~2°C/s Footprint Dimensions 390 x 257 x 207 mm (L x W x H) Weight 7 kg Computervereisten Compatible operating systems Windows 7 or higher, MacOS 10.11 or higher Compatible file format Gerber Connection type Wired USB Certificatie EN 61326-1:2013 EMC requirements IEC 61010-1 Safety requirements CE Marking Affixed to the Voltera V-One printers delivered to European customers Ontworpen en geassembleerd in Canada.Meer technische informatieQuickstartExplore Flexible Printed Electronics on the V-OneVoltera V-One Capabilities ReelVoltera V-One PCB Printer WalkthroughUnpackingV-One: Solder Paste Dispensing and Reflow All in OneVoltera @ Stanford University's Bao Research Group: Robotic Skin and Stretchable SensorsVoltera @ Princeton: The Future of Aerospace Innovation

Lees meer minder

Unitree Go1 series consists of quadruped robots for the research & development of autonomous systems in the fields of human-robot interaction (HRI), SLAM & transportation. Due to the four legs, as well as the 12DOF, this robot can handle a variety of different terrains. The Go1 comes with a perfected drive & power management system, which enables a speed (depending on the version) of up to 3.7 m/s or 11.88 km/h with an operating time of up to 2.5 hours. Furthermore, the motors have a torque of 23.70N.m at the body/thighs and 35.55N.m at the knees, which also allow jumps or backflips.Features High Dynamics 17 km/h Intelligent Side-Follow System (ISS) Super Sensory System (SSS) 10-view Detection AI Detection, Human Recognition, etc. Flexible and adaptive Joints Long Endurance Specifications Light and Compact Weight: 12 kg Size (folded): 0.588 x 0.29 x 0.22 m High Performance Max Speed: 4.7 m/s (17 kmh or 10.6 mph) Intelligent Side Follow System (Adopt Patented Wireless Vector Positioning and Control Technology) Robot dog can walk alongside its owner and not only follow The human-machine interaction is both harmonious and safe Super Sensory System Full View Coverage 5 Sets Fish-Eye Stereo Depth Cameras + AI Post-processing + 3 Sets of Hypersonic Sensors Lens Angle: 150 x 170° Built-in Powerful AI 16-core CPU + GPU (384 Cores, 1.5 TFLOPS) ISS and SSS Function Cooperatively Strong & Reliable Power System New Power Joint with Super Lightweight Low Noise and Long Life Heat Pipe Cooling System Built in the Knee Joint Motor Body/thigh joints: C1-8: 520 g 23.70N.m Knee Joint: C1-8 x 1.5 ratio 35.55N.m Unitree Go1 Variants: Go1 Air, Go1 Pro, Go1 EduThe Go1 series has 3 variants (Go1 Air, Go1 Pro and Go1 Edu), which differ a little technically. The differences are mainly the processors and sensor systems, the Air and Pro variant works, depending on the model, with one or 3x (4x 1.43 GHz 128 Cores 0.5 T) processor as well as with 1 or 5 super sensor systems. Both variants are equipped with 3 ultrasonic sensors. The Go1 Edu variant has up to 3 nano processors, 5 super sensor systems, and 4 ultrasonic sensors.Air vs Pro vs Edu Go1 Air Go1 Pro Go1 Edu SSS 1 Super-sensing system 1 set 5 sets 5 sets Sensing calculation 1x (4x 1.43 GHz 128 Cores 0.5 T) 3x (4x 1.43 GHz 128 Cores 0.5 T) 2 Nano + (1 Nano or 1 NX) ISS 1 Intelligent Concomitant ✓ ✓ ✓ RTT 1 Pictures Transaction ✓ ✓ ✓ Charger 24 V, 4 V 24 V, 6 V 24 V, 6 V Remote Control ✓ ✓ ✓ Load ≈3 kg ≈3 kg ≈5 kg (max ~10 kg) Heat Pipe Assisted Heat Dissipation ✓ ✓ ✓ Motion Speed 0~2.5 m/s 0~3.5 m/s 0~3.7 m/s (max ~5 m/s) Battery 1x 1x 1x Graphical Programming Interface ✓ ✓ ✓ Scientific Programming Interface ✓ Python Programming Interface ✓ HAI 1 Human Sensing ✓ APP Top View ✓ ✓ 4G ✓ Foot-end Physical Force Sensor ✓ Multifunctional Peripheral Expansion Interface ✓ Radar 2D or 3D optional Included 1x Unitree Go1 1x Unitree Go1 Battery 1x Unitree Go1 Charger 1x Unitree Go1 Remote Controller Downloads User Manual GitHub

Lees meer minder

Unitree Go1 series consists of quadruped robots for the research & development of autonomous systems in the fields of human-robot interaction (HRI), SLAM & transportation. Due to the four legs, as well as the 12DOF, this robot can handle a variety of different terrains. The Go1 comes with a perfected drive & power management system, which enables a speed (depending on the version) of up to 3.7 m/s or 11.88 km/h with an operating time of up to 2.5 hours. Furthermore, the motors have a torque of 23.70N.m at the body/thighs and 35.55N.m at the knees, which also allow jumps or backflips.Features High Dynamics 17 km/h Intelligent Side-Follow System (ISS) Super Sensory System (SSS) 10-view Detection AI Detection, Human Recognition, etc. Flexible and adaptive Joints Long Endurance Specifications Light and Compact Weight: 12 kg Size (folded): 0.588 x 0.29 x 0.22 m High Performance Max Speed: 4.7 m/s (17 kmh or 10.6 mph) Intelligent Side Follow System (Adopt Patented Wireless Vector Positioning and Control Technology) Robot dog can walk alongside its owner and not only follow The human-machine interaction is both harmonious and safe Super Sensory System Full View Coverage 5 Sets Fish-Eye Stereo Depth Cameras + AI Post-processing + 3 Sets of Hypersonic Sensors Lens Angle: 150 x 170° Built-in Powerful AI 16-core CPU + GPU (384 Cores, 1.5 TFLOPS) ISS and SSS Function Cooperatively Strong & Reliable Power System New Power Joint with Super Lightweight Low Noise and Long Life Heat Pipe Cooling System Built in the Knee Joint Motor Body/thigh joints: C1-8: 520 g 23.70N.m Knee Joint: C1-8 x 1.5 ratio 35.55N.m Unitree Go1 Variants: Go1 Air, Go1 Pro, Go1 EduThe Go1 series has 3 variants (Go1 Air, Go1 Pro and Go1 Edu), which differ a little technically. The differences are mainly the processors and sensor systems, the Air and Pro variant works, depending on the model, with one or 3x (4x1.43 GHz 128 Cores 0.5 T) processor as well as with 1 or 5 super sensor systems. Both variants are equipped with 3 ultrasonic sensors. The Go1 Edu variant has up to 3 nano processors, 5 super sensor systems, and 4 ultrasonic sensors.Air vs Pro vs Edu Go1 Air Go1 Pro Go1 Edu SSS 1 Super-sensing system 1 set 5 sets 5 sets Sensing calculation 1x (4x 1.43 GHz 128 Cores 0.5 T) 3x (4x 1.43 GHz 128 Cores 0.5 T) 2 Nano + (1 Nano or 1 NX) ISS 1 Intelligent Concomitant ✓ ✓ ✓ RTT 1 Pictures Transaction ✓ ✓ ✓ Charger 24 V, 4 V 24 V, 6 V 24 V, 6 V Remote Control ✓ ✓ ✓ Load ≈3 kg ≈3 kg ≈5 kg (max ~10 kg) Heat Pipe Assisted Heat Dissipation ✓ ✓ ✓ Motion Speed 0~2.5 m/s 0~3.5 m/s 0~3.7 m/s (max ~5 m/s) Battery 1x 1x 1x Graphical Programming Interface ✓ ✓ ✓ Scientific Programming Interface ✓ Python Programming Interface ✓ HAI 1 Human Sensing ✓ APP Top View ✓ ✓ 4G ✓ Foot-end Physical Force Sensor ✓ Multifunctional Peripheral Expansion Interface ✓ Radar 2D or 3D optional Included 1x Unitree Go1 1x Unitree Go1 Battery 1x Unitree Go1 Charger 1x Unitree Go1 Remote Controller Downloads User Manual GitHub
