3 producten

  • PeakTech 4350 Clamp Meter

    PeakTech PeakTech 4350 Clamp Meter

    AC/DC True RMS Current Clamp Meter (3 4/5-digit)This power clamp meter in the most modern design is suitable for small cable diameters up to 17 mm, leakage currents up to 5 A in high-precision resolution of 1 mA and also currents up to 80 A with 100 mA resolution. Furthermore, this device is topped by its exact measurement functions for voltage, current, capacitance, resistance and frequency measurements, as well as a temperature measurement with the enclosed K-Type probe.In addition to the measurement features, the device also offers function keys for minimum and maximum value display, a data hold function and a switchable LED flashlight for the measuring area. Through this and also the True RMS measurement, this device is the perfect tool for every electrician in the energy and building sector and other service technicians in the wide range of electronics.Features 3 4/5-digits 27mm LCD display (max. 4999) with backlight illumination Current measurements up to 5 A at 1 mA resolution Current measurements up to 80 A with 100 mA resolution Multimeter measurement functions for voltage, frequency, resistance and capacitance Continuity and diode test Temperature measurement function with K-type probe Data-Hold, MAX/MIN-Hold Relative value measurement function LED to measuring station lighting Auto Power Off Safety: EN 61010-1, CAT III 600 V Accessories: Case, test leads, K-Type thermocouple, battery and manual Specifications DCV 500 mV/5/50/500/600 V; 0,1 mV; +/- 1,5 % + 2 dgt. ACV 500 mV/5/50/500/600 V; 0,1 mV; +/- 2,0 % + 4 dgt., Frequency range: 40 ... 400 Hz DCA 5000 mA/80 A; 1 mA; +/- 2,5 % + 30 dgt. ACA 5000 mA/80 A; 1 mA; +/- 2,5 % + 25 dgt. Frequency range: 40 ... 400 Hz Ohm 500 ?/5/50/500 k?/5/50 M?; 0,1 ?; +/- 1,5 % + 2 dgt. Capacitance 50/500 nF/5/50/500 µF; 10 pF; +/- 3,5 % + 10 dgt. Frequency 5 Hz ... 10 MHz; 1 mHz; +/- 1,2 % + 3 dgt. Temperature -20 ... +760°C; 0,1°C; +/- 2,0 % + 3°C Operation voltage 9 V-Battery Dimensions (WxHxD) 70 x 210 x 37 mm Weight 200 g

    € 79,95

    Leden € 71,96

  • UNI-T UT216B Digital Clamp Meter

    Uni-Trend UNI-T UT216B Digital Clamp Meter

    Niet op voorraad

    De UT216B (600 A) True RMS digitale stroomtang is ontworpen voor het meten van hoogfrequente stromen (tot 400 Hz) in serverruimtes, IT-systemen, etc. Het ontwerp met dubbele injectie geeft gebruikers een comfortabelere grip en langere levensduur. Het 6000 count display van de UT216B biedt gebruikers ook nauwkeurigere metingen.Specificaties AC-stroom (600 A) ±2,5% +5 AC-stroom frequentiebereik 40 ~ 400 Hz AC-spanning (750 V) ±1,2% +5 AC-spanning frequentiebereik 40 ~ 400 Hz DC-spanning (1000 V) ±0,8% +1 Weerstand (60 M?) ±1% +2 Capaciteit (60 mF) ±4% +5 Frequentie (10 Hz~1 MHz) ±0,1% +4 Voeding 3x 1,5 V batterij (R03) Display 38 x 24 mm Afmetingen 220 x 75 x 40 mm Gewicht 232 g Kenmerken Digits weergave 6000 Auto range ? Tang opening 30 mm True RMS ? Diode (ongeveer 3,0 V) ? V.F.C. ? NCV ? Data hold ? Relatieve modus ? MAX/MIN ? LCD backlight ? Lampje ? Auto power off ? Buzzer voor continuïteitstest ? Batterij indicatie (?3,6 V) ? Ingangsbeveiliging ? Ingangsimpedantie voor DCV (?10 M?) ? Inbegrepen UT216B stroomtang Batterijen Meetsnoeren Downloads Datasheet Gebruikershandleiding

    Niet op voorraad

    € 79,95

    Leden € 71,96

  • PCW05A True RMS Clamp Meter (600 A)

    PCWork PCW05A True RMS Clamp Meter (600 A)

    The PCW05A True RMS Digital Clamp Meter is a versatile and reliable tool that can be used for a variety of applications. It can measure AC/DC voltage, current, resistance, capacitance, frequency, duty ratio, and temperature. The digital clamp meter is equipped with an Auto-Range function, which can detect automatically the correct measurement range for the chosen measurement function, making it very user-friendly. The 6000 counts display provides precise result read-outs. The LPF (Low Pass Filter), LowZ (Low Impedance), & DCA ZERO (Zero Correction) functions ensure accurate measurements. With its backlight LCD display and LED work light, the PCW05A can provide clear readings in low-light conditions. In addition, the bi-color display changes its color to orange in order to warn the user when measuring high current or voltage. Overall the PCW05A digital clamp meter is the perfect choice for professionals and hobbyists alike. Features CAT III 600 V; measures up to 600 A AC/DC current 6000 counts, True RMS Auto Range function Jaw opening: 2,5 cm AC/DC voltage, AC/DC current, resistance, capacitance, frequency, duty ratio, and temperature measurement NCV (non-contact voltage detection), continuity, and diode test Bi-color backlight LCD display (changes color to orange when measuring high currents / voltages) LPF (Low Pass Filter), LowZ (Low Impedance), & DCA ZERO (Zero Correction) functions Data hold with Max/Min function LED work light for working in dark environments Small and compact size making it a very handy tool Great packaging design and manual with pictures in various languages: EN, GER, ES, FR, PT, PL, IT Includes batteries, high-quality test leads, temperature probe, & transport case

    € 44,95

    Leden € 40,46
