De FNIRSI SWM-10 is een efficiënte, praktische en gemakkelijk mee te nemen draagbare puntlasser, met een ingebouwde 5000 mAh lithium accu, die ook als powerbank kan fungeren. De double-pulse puntlas technologie maakt het lassen stabieler en robuuster.
Kenmerken
5000 mAh lithium accu voor een lange levensduur
Snel opladende powerbank
Hoge resolutie 1,8" TFT LCD kleurenscherm
Ingebouwde intelligente temperatuur regelsensor, beveiliging tegen oververhitting, te lage voedingsspanning en kortsluiting
Aanpasbare instellingen voor voorverwarmen, pulseren, interval en het aantal laspunten maken het lassen stabieler en veiliger
Geschikt voor het lassen van nikkel plaatjes, ijzeren plaatjes, roestvrijstalen plaatjes, enz. De maximale lasdikte is 0,25 mm, en de lasstroom is 1200 A.
Specificaties
Lasdikte
Capaciteit
5000 mAh
Opladen
5 V / 2,1 A
Ontladen
5 V / 2,1 A
Te lassen materiaal
Nikkel, ijzer, roestvrijstaal, aluminium
Lasdikte
0,1 - 0,25 mm
Maximale lasstroom
1200 A
Gear
4 Combinaties gear aanpassing
Afmetingen
155 x 82 x 28 mm
Inbegrepen
1x FNIRSI SWM-10 puntlasser
2x Puntlas pennen
1x Nikkel plaatmateriaal
2x Reserve pennen
1x USB kabel
1x Manual
Downloads
Manual
Firmware V1.4
De EggBot is een gemakkelijk te bedienen open-source robot, die allerlei vormen kan tekenen op bolvormige en eivormige voorwerpen. De EggBot heeft een groot aantal instelmogelijkheden en kan bijvoorbeeld tekenen en op eieren, maar ook golfballen, gloeilampen, kerstballen en zelfs wijnglazen.
Mogelijkheden van de EggBot Deluxe
Gebruik de bot om indrukwekkende paaseieren te creëren, maak uw eigen kerstversiering of personaliseer uw golfballen. De EggBot is niet alleen een cool gadget, het biedt ook een geweldige introductie in de wereld van CNC (Computer Numerical Control) en doe-het-zelf robotica. Alle elektronica en software in de Eggbot kunt u aanpassen en zelfs voor andere toepassingen gebruiken.
Hoe werkt de robot?
De EggBot wordt aangeboden in vorm van een bouwpakket en wordt geleverd inclusief een universele netvoeding (met US-EU-adapter). De Eggbot is makkelijk in elkaar te zetten in een paar uur en heeft alleen een paar basis tools nodig zoals een platte schroevendraaier. Solderen is niet nodig.
Met behulp van de EggBot-software, open source, kunt u deze machine aansturen vanuit Inkscape, een uitstekend freeware illustratieprogramma (voor Mac-, Windows-en Linux-computers). U kunt zelf een afbeelding tekenen, een foto inscannen of ontwerpen uit andere programma's importeren. U kunt de EggBot ook vanuit veel andere programma’s aansturen wanneer deze de mogelijkheid bezitten om seriële commando’s te versturen via een USB-poort.
Done printing? Let’s add some components! Just be sure to use the Voltera recommended solder wire and plenty of flux to ensure a strong solder joint. Voltera has chemically tested it to be most compatible with their ink.
Alloy: Sn42 Bi57 Ag1
Dia: 1.0 mm
Flux: 2%
Weight: 20g
Recommended Temp: < 205°C (400°F)
RoHS Compliant
If you're hand soldering components with the provided solder wire, make sure to use flux to promote solder wetting. Out of solder wire? The wire in our store has been tested for best performance with the conductive ink and standard copper.
Use the right tool for the right job. These steel stakes are used to press the rivets on the PCB after holes have been drilled. They have been designed for optimum performance on the ink and ensure an electrical connection between the top and bottom layers of your PCB. Learn how to use them here.
Do you need a way to connect the top and bottom layers? Rivets are the key!Rivets are little copper tubes that make a mechanical connection between the top and bottom layer. We found rivets to be the easiest way to create vias. Be sure to pick up the corresponding rivet tool if you don't have one!
Pack of 200
Inner Diameter - 0.4mm
Head Diameter - 0.9mm
Drill Size: 0.7mm
Confused on how to use them? Checkout our tutorial here.
Use the right tool for the right job. These steel stakes are used to press the rivets on the PCB after holes have been drilled. They have been designed for optimum performance on the ink and ensure an electrical connection between the top and bottom layers of your PCB. Learn how to use them here.
Do you need a way to connect the top and bottom layers? Rivets are the key!Rivets are little copper tubes that make a mechanical connection between the top and bottom layer. We found rivets to be the easiest way to create vias. Be sure to pick up the corresponding rivet tool if you don't have one!
Pack of 200
Inner Diameter - 1.0mm
Head Diameter - 2.2mm
Drill Size: 1.5mm (or 1.6mm)
Confused on how to use them? Checkout our tutorial here.
The Conductor 3 ink is optimized for printing both rigid and flexible circuits. The printer lays down silver conductive ink to make the traces and pads that comprise your circuit board. After thermal curing, the ink is conductive and ready for reflow.
Specificaties
Recommended curing temperature is 90°C for 5 minutes, then 120°C for 20 minutes (temperature measured at ink surface).
Compatible with FR1, FR4, and flexible substrates.
For best results, cure immediately after printing.
Solder with tin-bismuth-silver solder wire and flux at 180°C, or use preset profile for reflow soldering.
Note: Cartridges must be kept refrigerated, and have a shelf life of 12 months.
T5 Particle size. Smaller particles means less clogging and more consistent dispensing!Fed up with ordering multiple stencils in between board iterations?Just snap on this RoHS solder paste cartridge and the V-One will dispense solder paste onto the pads of your board. Solder paste can be dispensed onto your V-One printed boards, or prefabricated circuit boards.
Particle Size: T5
Alloy: Sn42Bi57.6Ag0.4
Each cartridge prints approximately 11,000 0603 pads.
1 x 2mL cartridge
Use with 225um or 150um nozzles for best performance.
Soldeerpasta doseren en reflowen in één
De Voltera V-One maakt dubbellaags prototype printplaten op uw eigen bureau. Gerber-bestanden gaan erin, geprinte printplaten komen eruit. De dispenser legt een zilver-gebaseerde geleidende inkt om uw schakeling ter plekke te printen. Het assembleren van printplaten is eenvoudig met de V-One's soldeerpasta verdeler en reflow functies. Plaats uw printplaat op het printbed en importeer uw Gerber-bestand in Voltera's software.
Geen stencils meer nodig
Voltera's software is ontworpen om gemakkelijk mee uit de voeten te kunnen. Vanaf het importeren van uw Gerber-bestanden tot het moment dat u op print drukt, leidt de software u veilig door elke stap.
Compatibel met EAGLE, Altium, KiCad, Mentor Graphics, Cadence, DipTrace, Upverter.
De V-One Desktop PCB Printer wordt geleverd met alle accessoires en benodigdheden die nodig zijn om aan de slag te gaan:
In de verpakking
1 Conductor 2 cartridge
1 Solder Paste cartridge
10 2"x3" FR4 substrates
6 3"x4" FR4 substrates
10 2"x3" FR1 substrates
6 3"x4" FR1 substrates
25 disposable 230 micron nozzles
1 Burnishing pad
1 Solder wire spool
1 Drill bit set
200 0.4 mm rivets
200 1.0 mm rivets
2 Rivet tools
1 Sacrificial layer
1 Hello World starter kit
1 Punk Console starter kit
Accessories
2 Substrate clamps and thumbscrews
2 Dispensers with caps
1 Probe
1 Drill
1 Set of safety glasses
1 Voltera anti-static tweezers
Downloads
Specifications
V-One Software
User manuals
Safety datasheets
Technical datasheets
Voltera CAM file for EAGLE
Substrates and templates
Meer Info
Frequently Asked Questions
More from the Voltera community
Technische Specificaties
Printspecificaties
Minimum trace width
0.2 mm
Minimum passive size
1005
Minimum pin-to-pin pitch (conductive ink)
0.8 mml
Minimum pin-to-pin pitch (solder paste)
0.5 mml
Resistivity
12 mΩ/sq @ 70 um height
Substrate material
FR4
Maximum board thickness
3 mm
Soldeerspecificaties
Solder paste alloy
Sn42/Bi57.6/Ag0.4
Solder wire alloy
SnBiAg1
Soldering iron temperature
180-210°C
Drukbed
Print area
135 x 113.5 mm
Max. heated bed temperature
240°C
Heated bed ramp rate
~2°C/s
Footprint
Dimensions
390 x 257 x 207 mm (L x W x H)
Weight
7 kg
Computervereisten
Compatible operating systems
Windows 7 or higher, MacOS 10.11 or higher
Compatible file format
Gerber
Connection type
Wired USB
Certificatie
EN 61326-1:2013
EMC requirements
IEC 61010-1
Safety requirements
CE Marking
Affixed to the Voltera V-One printers delivered to European customers
Ontworpen en geassembleerd in Canada.
Meer technische informatie
Quickstart
Explore Flexible Printed Electronics on the V-One
Voltera V-One Capabilities Reel
Voltera V-One PCB Printer Walkthrough
Unpacking the V-One
V-One: Solder Paste Dispensing and Reflow All-in-One
Voltera @ Stanford University's Bao Research Group: Robotic Skin and Stretchable Sensors
Voltera @ Princeton: The Future of Aerospace Innovation
Keep printing with a pack of 4 nozzles (225 micron inner diameter). These metal dispensing tips offer excellent resolution and accurate deposition of ink and solder paste.
If you want to push the resolution limits of the V-One, these dispensing tips will help enable your experimental projects. This pack contains 4 extra fine nozzles with an internal diameter of 0.150 mm (6 mil).
Do not use with solder paste! It will clog!
Looking to dispense materials with a lower viscosity? These are the nozzles for you. Don't use this with our standard ink or solder paste... that will result in poor performance.This pack contains 4 extra fine nozzles with an internal diameter of 0.100 mm (4 mil)
The Hello World circuit is the first circuit you print with your V-One. Have more than one person using your V-One? Then you might want more Hello World kits!The Hello World kit contains:
6x Green LEDs
3x 47k Resistors
3x 180R Resistors
3x 100k Resistors
3x 4.7UF Capacitor
1x 555 timer
1x 9V battery
De SUNKKO 737G+ puntlasser is een krachtig en veelzijdig hulpmiddel dat is ontworpen voor naadloos en nauwkeurig lassen, met name voor 18650-batterijpakketten. Hij geeft prioriteit aan veiligheid en is uitgerust met een zekering van 30 A voor 220 V, waardoor bescherming tegen potentiële elektrische gevaren wordt gegarandeerd en gebruikers gemoedsrust krijgen tijdens het gebruik.
Voor een beter aanpassingsvermogen biedt het lasapparaat de mogelijkheid tot automatische of voetpedaalbediening, zodat u tussen modi kunt schakelen op basis van uw behoeften en voorkeuren. Of u nu aan ingewikkelde projecten of grotere taken werkt, deze flexibiliteit zorgt ervoor dat u te allen tijde volledige controle heeft.
Met een robuust nominaal vermogen van 4,3 kW levert de SUNKKO 737G+ het vermogen dat nodig is voor efficiënt en effectief lassen. Het geavanceerde pulscontrolesysteem beschikt over vier pulstijdinstellingen variërend van 2 tot 20 milliseconden, en acht uitgebreide pulstijdinstellingen tussen 8 en 80 milliseconden. Dankzij dit precisieniveau kunt u het lasproces afstemmen op elke specifieke taak, zodat u keer op keer verzekerd bent van hoogwaardige resultaten.
Bovendien ondersteunt de lasser een maximale lasdikte van 0,35 mm, waardoor hij geschikt is voor een verscheidenheid aan batterijformaten en materialen. Deze veelzijdigheid, gecombineerd met zijn geavanceerde functies, maakt de SUNKKO 737G+ een uitstekende keuze voor zowel professionals als hobbyisten die op zoek zijn naar betrouwbare, efficiënte en veilige lasprestaties.
BELANGRIJK: voor dit apparaat is een stroomonderbreker van 25 A vereist. Niet gebruiken met een kleinere stroomonderbreker!
Kenmerken
Max. uitgangsvermogen: 4,3 kW (onmiddellijk)
Ingangsspanning: 220 V
Lasstroom: 120-1200 A
Enkele pulstijd: 5 ms
Max. pulshoeveelheid: 18
Zekering: 30 A
Max. lasdikte: 0,35 mm
Automatisch puntlassen
Lassen met voetpedaal
Afmetingen: 14 x 25 x 20 cm
Gewicht: 7 kg
Inbegrepen
1x 737G+ puntlasmachine
1x S70BN mobiele laspen
1x Koperen lasstaven
1x Minimolen met USB-kabel
1x Koperen laspinnen voor mobiele pen
1x Batterijhouder
1x Voetpedaal
2x Zekeringen
1x Zeskantsleutel
50x Vernikkeld staal (0,15 x 8 x 100 mm)
50x Vernikkeld staal (0,1 x 4 x 100 mm)
1x Manual
Downloads
Manual
To protect the V-One from any damage during drilling, mount this piece of FR1 on the heated bed and clamp your substrate on top. The V-One Drill attachment will perforate your substrate but won't make it through this layer so your heated bed stays intact. Only one is included, but don't worry, the sacrifical layer can be reused plenty of times.
The Punk Console circuit is an advanced tutorial to get you familiar with the V-One Drill attachment. Learn how to create a double sided board and turn the knobs to create music! The kit contains: 2x Green LEDs 8x 1k Resistors 3x 0.01uF Capacitor 2x 500K Trimpots 1x 556 Timer 1x Piezo Buzzer 1x 9 V Battery 1x 9 V Battery Connector Rivets and a V-One Drill are required.
These boards are the maximum substrate size the V-One can handle. Just clamp them to the printing platform and press print to dispense the ink.
Pack of 6
Exact size is 4” x 5.3”
The V-One Drill includes everything you need to start making double sided boards right away: Drill Bit set (0.7 m, 0.8 mm, 0.9 mm, 1.0 mm, 1.6 mm) Sacrificial Layer (Black FR1) Copper Rivets (2 sizes, 200 pcs) Safety Glasses (clear) Rivet Tools (2 sizes) Hey Key Also included Power Supply (12 V, 25 W) Power Cable (1.8 m) Power Adapter Zip Ties (2 pcs) 4 Long Thumbscrews (10 mm) 2' x 3' FR1 Substrates (10 pcs) 3' x 4' FR1 Substrates (6 pcs) Zip Tie Mount
A set of high precision drill bits, covering the most common drill bit sizes. Just pop them in the V-One Drill with a 2.5 mm hex key (not included) and start drilling. The following sizes are included (2 of each): 0.70 mm 0.80 mm 0.90 mm 1.00 mm 1.60 mm
When you start to run out of space in your design, migrate over from the small substrates to these. These substrates are made of FR1 – which means they don't contain fibreglass. There is less wear on the drill bits. Download the template and incorporate them into your design here. 6 substrates included.
