This ebook is about the Raspberry Pi 3 computer and its use in various control and monitoring applications. The book explains in simple terms and with tested and working example projects, how to configure the Raspberry Pi 3 computer, how to install and use the Linux operating system, and how to write hardware based applications programs using the Python programming language.
The nice feature of this book is that it covers many Raspberry Pi 3 based hardware projects using the latest hardware modules such as the Sense HAT, Swiss Pi, MotoPi, Camera module, and many other state of the art analog and digital sensors. An important feature of the Raspberry Pi 3 is that it contains on-board Bluetooth and Wi-Fi modules. Example projects are given in the book on using the Wi-Fi and the Bluetooth modules to show how real-data can be sent to the Cloud using the Wi-Fi module, and also how to communicate with an Android based mobile phone using the Bluetooth module.
The book is ideal for self-study, and is intended for electronic/electrical engineering students, practising engineers, research students, and for hobbyists. It is recommended that the book should be followed in the given Chapter order.
Over 30 projects are given in the book. All the projects in the book are based on the Python programming language and they have been fully tested. Full program listings of every project are given in the book with comments and full descriptions. Experienced programmers should find it easy to modify and update the programs to suit their needs.
The following sub-headings are given for each project to make it as easy as possible for the readers to follow the projects:
Project title
Description
Aim of the project
Raspberry Pi type
Block diagram
Circuit diagram
Program listing
Like the Raspberry Pi 3 B+, the Raspberry Pi 3 A+ boasts a 64-bit quad-core processor running at 1.4 GHz, dual-band 2.4 GHz and 5 GHz wireless LAN, and Bluetooth 4.2/BLE. The dual-band wireless LAN comes with modular compliance certification, allowing the board to be designed into end products with significantly reduced wireless LAN compliance testing, improving both cost and time to market. The Raspberry Pi 3 A+ has the same mechanical footprint as the Raspberry Pi 1 A+.
Specifications
Processor
Broadcom BCM2837B0, Cortex-A5364-bit SoC @ 1.4 GHz
Memory
512 MB LPDDR2 SDRAM
Connectivity
2.4 GHz and 5 GHz IEE 802.11.b/g/n/ac wireless LANBluetooth 4.2/BLE
Video & Sound
1x full size HDMIMIPI DSI display portMIPI CSI camera port4 pole stereo output and composite video port
Multimedia
H.264, MPEG-4 decode (1080p30)H.264 encode (1080p30)OpenGL ES 1.1, 2.0 graphics
SD Card support
Micro SD format for loading operating system and data storage
Input Power
5 V/2.5 A DC via micro-USB connector5 V DC via GPIO header
Environment
Operating temperature, 0-50°C
Dimensions
65 x 56.5 mm
Vergeleken met de eigenschappen van zijn voorganger, zijn de snelheid en het vermogen van deze Raspberry Pi 3 B+ met 15% toegenomen zonder de compatibiliteit (elektrisch en mechanisch) met de Raspberry Pi 3 B, 2 en B+ modellen te belemmeren.
Features
Quad-core processorversnelling: ongeveer 10% meer verwerkingscapaciteit
Ondersteuning voor H.264 MPEG-4, H.264 en Open GL ES 1.1 & 2.0 grafisch beheer
1 GB LPDDR2 SDRAM
802.11ac dual band draadloze communicatie (2,4 GHz/5 GHz)
Power over Ethernet (PoE) mogelijk
Nieuwe Ethernet controller
Verbeterde energiebeheer
Verbeterde thermisch beheer
Nu met WiFi 802.11ac (2.4 GHz/5 GHz)
Verhoogde verbindingssnelheid en bandbreedte
Groter bereik wanneer aangesloten op het 5 GHz-kanaal
Achterwaartse compatibiliteit binnen toepassingen
Verbeterde streaming HD-video via WiFi
Verhoogde effectiviteit als draadloos toegangspunt
Verbeterde rekenprestatie
Snellere core processor (4x 1,4 GHz)
Voeding over Ethernet mogelijk
PoE dankzij de PoE HAT (binnenkort beschikbaar)
De RPi 3 B+ heeft voor zijn voedingsstroom geen stopcontact meer nodig, hij kan ergens ver weg (<100 m) via de ethernet verbinding gevoed worden.
Daardoor worden installatie en distributie van Raspberry Pi netwerken eenvoudiger en effectiever
Nieuwe Ethernet controller
Ethernet van de Raspberry Pi 3 B+ is 3x sneller (~300 Mbps)
Snellere gegevensoverdracht via het netwerk
Specificaties
SoC
Broadcom BCM2837B0 64bit ARMv8 quad-core CPU
CPU
ARM Cortex-A53 (64-bit) quad-core 1400 MHz
GPU
Dual-Core VideoCore IV Multimedia Co-Processor
RAM
1024 MB
USB
4x USB-A 2.0
GPIO
40 Pins
Ethernet
Gigabit Ethernet via USB 2.0
Wireless LAN
802.11b/g/n/ac (2.4 GHz/5 GHz)
Bluetooth
4.2 + LE
Audio/Video
4-polige stereo uitgang / composiete video poort
Aansluitingen
Full size HDMI / CSI camera / DSI display poort / microSD poort (verbeterd)
Voedingsaansluiting
Micro-USB (5 V | < 2,5 A)
Afmetingen
85 x 56 x 17 mm
Bespaar € 10 met deze starterkit in vergelijking met afzonderlijke aankoop!
Deze speciale Raspberry Pi 4 starterkit bevat alles wat je nodig hebt om meteen aan de slag te gaan met 's werelds populairste minicomputer als ontwikkel- en multimedia-apparaat.
Inhoud van de kit
Raspberry Pi 4 B (4 GB RAM)De Raspberry Pi 4 is een compleet computersysteem in een klein formaat dat multimedia en desktop prestaties levert die vergelijkbaar zijn met die van een basis x86 PC systeem.
Broadcom BCM2711 SoC 64-bit quad-core ARM Cortex-A72 (1,5 GHz)
VideoCore VI @ 500 MHz
4 GB LPDDR4 SDRAM
Gigabit Ethernet
802.11ac Wi-Fi
Bluetooth 5.0
2x USB 3.0, 2x USB 2.0 en 1x USB-C (voor stroomvoorziening)
2x micro-HDMI (tot 4Kp60)
1x MicroSD (voor opslag)
Officiële EU voeding (5,1 V, 3 A) voor Raspberry Pi 4 (wit)De officiële Raspberry Pi USB-C voeding (15,3 W) is speciaal ontworpen om de Raspberry Pi 4 van stroom te voorzien.
MicroSD kaart (32 GB, klasse 10) met SD adapter (voorgeïnstalleerd met NOOBS)Deze microSD met voorgeïnstalleerde NOOBS (New Out Of Box Software) is een eenvoudig te gebruiken installatiemanager voor het besturingssysteem van de Raspberry Pi.
Officiële behuizing voor (wit/rood)Deze perfect passende behuizing beschermt de Raspberry Pi 4.
Officiële HDMI kabel voor Raspberry Pi 4 (wit, 1 m)De officiële Raspberry Pi micro-HDMI naar HDMI (A/M) kabel (wit, 1 m) is ontworpen voor de Raspberry Pi 4.
Koellichaamset voor Raspberry PiDeze aluminium koellichamen koelen het board en voorkomen dat de Raspberry Pi oververhit raakt.
Bespaar € 10 met deze starterkit in vergelijking met afzonderlijke aankoop!
Deze speciale Raspberry Pi 4 starterkit bevat alles wat je nodig hebt om meteen aan de slag te gaan met 's werelds populairste minicomputer als ontwikkel- en multimedia-apparaat.
Inhoud van de kit
Raspberry Pi 4 B (8 GB RAM)De Raspberry Pi 4 is een compleet computersysteem in een klein formaat dat multimedia en desktop prestaties levert die vergelijkbaar zijn met die van een basis x86 PC systeem.
Broadcom BCM2711 SoC 64-bit quad-core ARM Cortex-A72 (1,5 GHz)
VideoCore VI @ 500 MHz
8 GB LPDDR4 SDRAM
Gigabit Ethernet
802.11ac Wi-Fi
Bluetooth 5.0
2x USB 3.0, 2x USB 2.0 en 1x USB-C (voor stroomvoorziening)
2x micro-HDMI (tot 4Kp60)
1x MicroSD (voor opslag)
Officiële EU voeding (5,1 V, 3 A) voor Raspberry Pi 4 (wit)De officiële Raspberry Pi USB-C voeding (15,3 W) is speciaal ontworpen om de Raspberry Pi 4 van stroom te voorzien.
MicroSD kaart (32 GB, klasse 10) met SD adapter (voorgeïnstalleerd met NOOBS)Deze microSD met voorgeïnstalleerde NOOBS (New Out Of Box Software) is een eenvoudig te gebruiken installatiemanager voor het besturingssysteem van de Raspberry Pi.
Officiële behuizing voor (wit/rood)Deze perfect passende behuizing beschermt de Raspberry Pi 4.
Officiële HDMI kabel voor Raspberry Pi 4 (wit, 1 m)De officiële Raspberry Pi micro-HDMI naar HDMI (A/M) kabel (wit, 1 m) is ontworpen voor de Raspberry Pi 4.
Koellichaamset voor Raspberry PiDeze aluminium koellichamen koelen het board en voorkomen dat de Raspberry Pi oververhit raakt.
De Raspberry Pi 4 B is 3x sneller dan zijn 3 B+ voorganger en biedt 4x snellere multimedia prestaties (vergelijkbaar met de desktop prestaties van een entry-level x86-gebaseerde PC).
Features
Krachtige 64-bit quad-core processor
Ondersteuning voor twee schermen met resoluties tot 4K via een paar micro-HDMI-poorten
Hardware videodecodering tot 4Kp60
Tot 8 GB RAM
Dual-band 2,4/5 GHz draadloze LAN
Bluetooth 5.0
Gigabit Ethernet
USB 3.0
PoE-mogelijkheid (via een aparte PoE HAT add-on)
Specificaties
SoC
Broadcom BCM2711
CPU
64-bit ARM Cortex-A72 (4x 1,5 GHz)
GPU
Broadcom VideoCore VI
RAM
Up to 8 GB LPDDR4
Wireless LAN
2,4 GHz and 5 GHz IEEE 802.11b/g/n/ac wireless LAN
Bluetooth
Bluetooth 5.0, BLE
Ethernet
Gigabit Ethernet
USB
2x USB-A 3.02x USB-A 2.0
GPIO
Standard 40-pin GPIO header (fully backwards-compatible with previous boards)
Video
2x micro-HDMI ports (up to 4Kp60 supported)2-lane MIPI DSI port (display)2-lane MIPI CSI port (camera)
Audio
4-pole stereo audio and composite video port
Multimedia
H.265 (4Kp60 decode)H.264 (1080p60 decode, 1080p30 encode)OpenGL ES, 3.0 graphics
SD card
microSD (for operating system and storage)
Power
5 V | 3 A (via USB-C)5 V | 3 A (via GPIO)Power over Ethernet (PoE) enabled – (requires separate PoE HAT)
Raspberry Pi 4 B
2 GB RAM
4 GB RAM
8 GB RAM
De Raspberry Pi 4 B is 3x sneller dan zijn 3 B+ voorganger en biedt 4x snellere multimedia prestaties (vergelijkbaar met de desktop prestaties van een entry-level x86-gebaseerde PC).
Features
Krachtige 64-bit quad-core processor
Ondersteuning voor twee schermen met resoluties tot 4K via een paar micro-HDMI-poorten
Hardware videodecodering tot 4Kp60
Tot 8 GB RAM
Dual-band 2,4/5 GHz draadloze LAN
Bluetooth 5.0
Gigabit Ethernet
USB 3.0
PoE-mogelijkheid (via een aparte PoE HAT add-on)
Specificaties
SoC
Broadcom BCM2711
CPU
64-bit ARM Cortex-A72 (4x 1,5 GHz)
GPU
Broadcom VideoCore VI
RAM
Up to 8 GB LPDDR4
Wireless LAN
2,4 GHz and 5 GHz IEEE 802.11b/g/n/ac wireless LAN
Bluetooth
Bluetooth 5.0, BLE
Ethernet
Gigabit Ethernet
USB
2x USB-A 3.02x USB-A 2.0
GPIO
Standard 40-pin GPIO header (fully backwards-compatible with previous boards)
Video
2x micro-HDMI ports (up to 4Kp60 supported)2-lane MIPI DSI port (display)2-lane MIPI CSI port (camera)
Audio
4-pole stereo audio and composite video port
Multimedia
H.265 (4Kp60 decode)H.264 (1080p60 decode, 1080p30 encode)OpenGL ES, 3.0 graphics
SD card
microSD (for operating system and storage)
Power
5 V | 3 A (via USB-C)5 V | 3 A (via GPIO)Power over Ethernet (PoE) enabled – (requires separate PoE HAT)
Raspberry Pi 4 B
1 GB RAM
4 GB RAM
8 GB RAM
De Raspberry Pi 4 B is 3x sneller dan zijn 3 B+ voorganger en biedt 4x snellere multimedia prestaties (vergelijkbaar met de desktop prestaties van een entry-level x86-gebaseerde PC).
Features
Krachtige 64-bit quad-core processor
Ondersteuning voor twee schermen met resoluties tot 4K via een paar micro-HDMI-poorten
Hardware videodecodering tot 4Kp60
Tot 8 GB RAM
Dual-band 2,4/5 GHz draadloze LAN
Bluetooth 5.0
Gigabit Ethernet
USB 3.0
PoE-mogelijkheid (via een aparte PoE HAT add-on)
Specificaties
SoC
Broadcom BCM2711
CPU
64-bit ARM Cortex-A72 (4x 1,5 GHz)
GPU
Broadcom VideoCore VI
RAM
Up to 8 GB LPDDR4
Wireless LAN
2,4 GHz and 5 GHz IEEE 802.11b/g/n/ac wireless LAN
Bluetooth
Bluetooth 5.0, BLE
Ethernet
Gigabit Ethernet
USB
2x USB-A 3.02x USB-A 2.0
GPIO
Standard 40-pin GPIO header (fully backwards-compatible with previous boards)
Video
2x micro-HDMI ports (up to 4Kp60 supported)2-lane MIPI DSI port (display)2-lane MIPI CSI port (camera)
Audio
4-pole stereo audio and composite video port
Multimedia
H.265 (4Kp60 decode)H.264 (1080p60 decode, 1080p30 encode)OpenGL ES, 3.0 graphics
SD card
microSD (for operating system and storage)
Power
5 V | 3 A (via USB-C)5 V | 3 A (via GPIO)Power over Ethernet (PoE) enabled – (requires separate PoE HAT)
Raspberry Pi 4 B
1 GB RAM
2 GB RAM
8 GB RAM
De Raspberry Pi 4 B is 3x sneller dan zijn 3 B+ voorganger en biedt 4x snellere multimedia prestaties (vergelijkbaar met de desktop prestaties van een entry-level x86-gebaseerde PC).
Features
Krachtige 64-bit quad-core processor
Ondersteuning voor twee schermen met resoluties tot 4K via een paar micro-HDMI-poorten
Hardware videodecodering tot 4Kp60
Tot 8 GB RAM
Dual-band 2,4/5 GHz draadloze LAN
Bluetooth 5.0
Gigabit Ethernet
USB 3.0
PoE-mogelijkheid (via een aparte PoE HAT add-on)
Specificaties
SoC
Broadcom BCM2711
CPU
64-bit ARM Cortex-A72 (4x 1,5 GHz)
GPU
Broadcom VideoCore VI
RAM
Up to 8 GB LPDDR4
Wireless LAN
2,4 GHz and 5 GHz IEEE 802.11b/g/n/ac wireless LAN
Bluetooth
Bluetooth 5.0, BLE
Ethernet
Gigabit Ethernet
USB
2x USB-A 3.02x USB-A 2.0
GPIO
Standard 40-pin GPIO header (fully backwards-compatible with previous boards)
Video
2x micro-HDMI ports (up to 4Kp60 supported)2-lane MIPI DSI port (display)2-lane MIPI CSI port (camera)
Audio
4-pole stereo audio and composite video port
Multimedia
H.265 (4Kp60 decode)H.264 (1080p60 decode, 1080p30 encode)OpenGL ES, 3.0 graphics
SD card
microSD (for operating system and storage)
Power
5 V | 3 A (via USB-C)5 V | 3 A (via GPIO)Power over Ethernet (PoE) enabled – (requires separate PoE HAT)
Raspberry Pi 4 B
1 GB RAM
2 GB RAM
4 GB RAM
Designed for overclockers and other power users, this fan keeps your Raspberry Pi 4 at a comfortable operating temperature even under heavy load. The temperature-controlled fan delivers up to 1.4 CFM of airflow over the processor, memory, and power management IC. The bundled heatsink (18 x 8 x 10 mm) with self-adhesive pad improves heat transfer from the processor. The Raspberry Pi 4 Case Fan works with Raspberry Pi 4 and the official Raspberry Pi 4 case.
Cool Projects for Test, Measurement, and Control
The Raspberry Pi has dominated the maker scene for many years. Freely accessible I/O pins have made it one of the most popular processor boards of all time. However, the classic Raspberry Pi has no analog inputs. Direct measurement of analog values is therefore not possible. Consequently, photodiodes, NTCs, Hall sensors, etc. cannot be read directly. In addition, the pins are connected directly to the exposed contacts, i.e. without a driver or protection circuit. This can quickly destroy the central controller and thus the entire Raspberry Pi.
These problems can be elegantly solved with the Pico. As a front-end, it can easily handle a wide range of measurement tasks. In addition, the Pico is much cheaper than a classic Raspberry Pi 4 or 5. If a faulty circuit leads to the destruction of the Pico, this is relatively easy to handle. This makes the combination of a classic Raspberry Pi 4 or 5 and the Pico an ideal pair.
The book introduces the broad and highly topical field of modern controller technology using the combined force of a Raspberry Pi 4 or 5 and a Raspberry Pi Pico. In addition to a detailed introduction to the operation and functionality of the controller boards themselves, the book also focuses on data acquisition and processing with digital processors. Especially the combination of both systems offers a wide range of interesting possibilities.
Some practical projects from the contents:
USB between Raspberry Pi 4 or 5 and Pico
I²C Communication and Pico as an I²C device
Voltmeter and Computer Thermometer
Pico W as a Web Server and WLAN Scanner
Frequency Meters and Generators
OLED Displays on Raspberry Pi 4 or 5 and Pico
Energy Saving Monitor
Which Astronauts are in Orbit?
Mini Monitor for Current Bitcoin Exchange Rate
Cool Projects for Test, Measurement, and Control
The Raspberry Pi has dominated the maker scene for many years. Freely accessible I/O pins have made it one of the most popular processor boards of all time. However, the classic Raspberry Pi has no analog inputs. Direct measurement of analog values is therefore not possible. Consequently, photodiodes, NTCs, Hall sensors, etc. cannot be read directly. In addition, the pins are connected directly to the exposed contacts, i.e. without a driver or protection circuit. This can quickly destroy the central controller and thus the entire Raspberry Pi.
These problems can be elegantly solved with the Pico. As a front-end, it can easily handle a wide range of measurement tasks. In addition, the Pico is much cheaper than a classic Raspberry Pi 4 or 5. If a faulty circuit leads to the destruction of the Pico, this is relatively easy to handle. This makes the combination of a classic Raspberry Pi 4 or 5 and the Pico an ideal pair.
The book introduces the broad and highly topical field of modern controller technology using the combined force of a Raspberry Pi 4 or 5 and a Raspberry Pi Pico. In addition to a detailed introduction to the operation and functionality of the controller boards themselves, the book also focuses on data acquisition and processing with digital processors. Especially the combination of both systems offers a wide range of interesting possibilities.
Some practical projects from the contents:
USB between Raspberry Pi 4 or 5 and Pico
I²C Communication and Pico as an I²C device
Voltmeter and Computer Thermometer
Pico W as a Web Server and WLAN Scanner
Frequency Meters and Generators
OLED Displays on Raspberry Pi 4 or 5 and Pico
Energy Saving Monitor
Which Astronauts are in Orbit?
Mini Monitor for Current Bitcoin Exchange Rate
De Raspberry Pi 400 biedt een quad-core 64-bits processor, 4 GB RAM, draadloos netwerken, uitvoer op twee schermen, 4K-videoweergave en een 40-pins GPIO-header. Het is een krachtige, compacte computer ingebouwd in een draagbaar toetsenbord.
Specificaties
Processor
Broadcom BCM2711 quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.8 GHz
RAM
4 GB LPDDR4-3200
Connectivity
Dual-band (2.4 GHz and 5.0 GHz) IEEE 802.11b/g/n/ac wireless LANBluetooth 5.0, BLEGigabit Ethernet2 × USB 3.0 and 1 × USB 2.0 ports
GPIO
Horizontal 40-pin GPIO header
Video & Sound
2 × micro HDMI ports (supports up to 4Kp60)
Multimedia
H.265 (4Kp60 decode)H.264 (1080p60 decode, 1080p30 encode)OpenGL ES 3.0 graphics
SD card support
MicroSD card slot for operating system and data storage
Keyboard
US keyboard
Power
5 V DC via USB connector
Operating temperature
0°C to +40°C
Dimensions
286 × 122 × 23 mm (maximum)
De Raspberry Pi 400 biedt een quad-core 64-bits processor, 4 GB RAM, draadloos netwerken, uitvoer op twee schermen, 4K-videoweergave en een 40-pins GPIO-header. Het is een krachtige, compacte computer ingebouwd in een draagbaar toetsenbord.
Specificaties (Raspberry Pi 400)
Processor
Broadcom BCM2711 quad-core Cortex-A72 (ARM v8) 64-bit SoC @ 1.8 GHz
RAM
4 GB LPDDR4-3200
Connectivity
Dual-band (2.4 GHz and 5.0 GHz) IEEE 802.11b/g/n/ac wireless LANBluetooth 5.0, BLEGigabit Ethernet2 × USB 3.0 and 1 × USB 2.0 ports
GPIO
Horizontal 40-pin GPIO header
Video & Sound
2 × micro HDMI ports (supports up to 4Kp60)
Multimedia
H.265 (4Kp60 decode)H.264 (1080p60 decode, 1080p30 encode)OpenGL ES 3.0 graphics
SD card support
MicroSD card slot for operating system and data storage
Keyboard
US keyboard
Power
5 V DC via USB connector
Operating temperature
0°C to +40°C
Dimensions
286 × 122 × 23 mm (maximum)
Inhoud van de kit
Raspberry Pi 400 (US layout, QWERTY)
Officiële EU voedingsadapter (5,1 V/3 A) voor Raspberry Pi 4 (wit)
Officiële Raspberry Pi muis (wit/rood)
Officiële HDMI-kabel voor Raspberry Pi 4 (wit, 1 m)
microSD-kaart (16 GB, Class 10) met SD-adapter (met voorgeïnstalleerde NOOBS)
The Official Raspberry Pi Beginner's Guide (4th Edition)
De Raspberry Pi 45 W USB-C Voeding is een ideale keuze voor het voeden van USB-C-compatibele Raspberry Pi-producten. Het is met name geschikt voor Raspberry Pi 5-gebruikers die randapparatuur met een hoog vermogen willen gebruiken, zoals harde schijven en SSD's.
Het levert tot 5,1 V/5 A en ondersteunt USB PD (Power Delivery)-onderhandeling, waardoor de Raspberry Pi 5 automatisch het optimale vermogensprofiel kan selecteren. Deze mogelijkheid stelt de Raspberry Pi 5 in staat om de USB-stroomlimiet te verhogen van de standaard 600 mA naar 1,6 A, wat extra vermogen levert voor randapparatuur die is aangesloten via de vier USB-A-poorten.
Dankzij het uitgebreide assortiment ingebouwde vermogensprofielen is de Raspberry Pi 45 W USB-C-voeding ook een uitstekende optie voor het voeden van PD-compatibele apparaten van derden, zoals smartphones, tablets en laptops. Beschikbare profielen zijn onder meer 9,0 V/5,0 A, 12,0 V/3,75 A, 15,0 V/3,0 A en 20,0 V/2,25 A, die allemaal maximaal 45 W leveren.
Specificaties
Ingang
100-240 V AC
Uitgang
5,1 V/5,0 A, 9,0 V/5,0 A, 12,0 V/3,75 A, 15,0 V/3,0 A, 20,0 V/2,25 A (Power Delivery)
Connector
USB-C
Kabel
1,5 m, 17AWG (wit)
Regio
EU
Downloads
Datasheet
De Raspberry Pi 5 levert meer prestaties dan ooit tevoren. Dankzij de snellere CPU, GPU en RAM is de Raspberry Pi 5 tot 3x sneller dan zijn ook al snelle voorganger. Naast de snelheidsboost biedt de Raspberry Pi 5 (die beschikt over het nieuwe Raspberry Pi RP1 silicium voor geavanceerde I/O-mogelijkheden) voor het eerst ook de volgende functies: RTC, een aan/uit-knop en een PCIe-interface.
Kenmerken
64-bit quad-core ARM Cortex-A76 processor (2,4 GHz)
VideoCore VII GPU (800 MHz)
16 GB LPDDR4X RAM (4267 MHz)
Raspberry Pi silicon RP1 I/O-controllerchip
Real-time clock
Aan/uit-knop
PCIe 2.0
UART-connector
Ventilatorconnector
Specificaties
SoC
Broadcom BCM2712
CPU
ARM Cortex-A76 (ARM v8) 64-bit
Kloksnelheid
4x 2,4 GHz
GPU
VideoCore VII (800 MHz)
RAM
16 GB LPDDR4X (4267 MHz)
WiFi
IEEE 802.11b/g/n/ac (2,4 GHz/5 GHz)
Bluetooth
Bluetooth 5.0, BLE
Ethernet
Gigabit Ethernet (met PoE+ ondersteuning)
USB
2x USB-A 3.0 (5 GBit/s)2x USB-A 2.0
PCI Express
1x PCIe 2.0
GPIO
Standaard 40-pins GPIO-header
Video
2x micro-HDMI poorten (4K60)2x 4-lane MIPI (DSI/CSI)
Multimedia
H.265 (4K60 decode)OpenGL ES 3.1, Vulkan 1.2
SD-kaart
microSD
Stroomvoorziening
5 V/5 A (via USB-C)Power over Ethernet (PoE+)
Raspberry Pi 5
2 GB RAM
4 GB RAM
8 GB RAM
Downloads
Datasheet
Unboxing the Raspberry Pi 5
First Insights
Program, build, and master over 60 projects with Python
The Raspberry Pi 5 is the latest single-board computer from the Raspberry Pi Foundation. It can be used in many applications, such as in audio and video media centers, as a desktop computer, in industrial controllers, robotics, and in many domestic and commercial applications. In addition to the well-established features found in other Raspberry Pi computers, the Raspberry Pi 5 offers Wi-Fi and Bluetooth (classic and BLE), which makes it a perfect match for IoT as well as in remote and Internet-based control and monitoring applications. It is now possible to develop many real-time projects such as audio digital signal processing, real-time digital filtering, real-time digital control and monitoring, and many other real-time operations using this tiny powerhouse.
The book starts with an introduction to the Raspberry Pi 5 computer and covers the important topics of accessing the computer locally and remotely. Use of the console language commands as well as accessing and using the desktop GUI are described with working examples. The remaining parts of the book cover many Raspberry Pi 5-based hardware projects using components and devices such as
LEDs and buzzers
LCDs
Ultrasonic sensors
Temperature and atmospheric pressure sensors
The Sense HAT
Camera modules
Example projects are given using Wi-Fi and Bluetooth modules to send and receive data from smartphones and PCs, and sending real-time temperature and atmospheric pressure data to the cloud.
All projects given in the book have been fully tested for correct operation. Only basic programming and electronics experience are required to follow the projects. Brief descriptions, block diagrams, detailed circuit diagrams, and full Python program listings are given for all projects described.
Program, build, and master over 60 projects with Python
The Raspberry Pi 5 is the latest single-board computer from the Raspberry Pi Foundation. It can be used in many applications, such as in audio and video media centers, as a desktop computer, in industrial controllers, robotics, and in many domestic and commercial applications. In addition to the well-established features found in other Raspberry Pi computers, the Raspberry Pi 5 offers Wi-Fi and Bluetooth (classic and BLE), which makes it a perfect match for IoT as well as in remote and Internet-based control and monitoring applications. It is now possible to develop many real-time projects such as audio digital signal processing, real-time digital filtering, real-time digital control and monitoring, and many other real-time operations using this tiny powerhouse.
The book starts with an introduction to the Raspberry Pi 5 computer and covers the important topics of accessing the computer locally and remotely. Use of the console language commands as well as accessing and using the desktop GUI are described with working examples. The remaining parts of the book cover many Raspberry Pi 5-based hardware projects using components and devices such as
LEDs and buzzers
LCDs
Ultrasonic sensors
Temperature and atmospheric pressure sensors
The Sense HAT
Camera modules
Example projects are given using Wi-Fi and Bluetooth modules to send and receive data from smartphones and PCs, and sending real-time temperature and atmospheric pressure data to the cloud.
All projects given in the book have been fully tested for correct operation. Only basic programming and electronics experience are required to follow the projects. Brief descriptions, block diagrams, detailed circuit diagrams, and full Python program listings are given for all projects described.
Program and Build Raspberry Pi 5 Based Ham Station Utilities with the RTL-SDR
The RTL-SDR devices (V3 and V4) have gained popularity among radio amateurs because of their very low cost and rich features. A basic system may consist of a USB based RTL-SDR device (dongle) with a suitable antenna, a Raspberry Pi 5 computer, a USB based external audio input-output adapter, and software installed on the Raspberry Pi 5 computer. With such a modest setup, it is possible to receive signals from around 24 MHz to over 1.7 GHz.
This book is aimed at amateur radio enthusiasts and electronic engineering students, as well as at anyone interested in learning to use the Raspberry Pi 5 to build electronic projects. The book is suitable for both beginners through experienced readers. Some knowledge of the Python programming language is required to understand and eventually modify the projects given in the book. A block diagram, a circuit diagram, and a complete Python program listing is given for each project, alongside a comprehensive description.
The following popular RTL-SDR programs are discussed in detail, aided by step-by-step installation guides for practical use on a Raspberry Pi 5:
SimpleFM
GQRX
SDR++
CubicSDR
RTL-SDR Server
Dump1090
FLDIGI
Quick
RTL_433
aldo
xcwcp
GPredict
TWCLOCK
CQRLOG
klog
Morse2Ascii
PyQSO
Welle.io
Ham Clock
CHIRP
xastir
qsstv
flrig
XyGrib
FreeDV
Qtel (EchoLink)
XDX (DX-Cluster)
WSJT-X
The application of the Python programming language on the latest Raspberry Pi 5 platform precludes the use of the programs in the book from working on older versions of Raspberry Pi computers.
Program and Build Raspberry Pi 5 Based Ham Station Utilities with the RTL-SDR
The RTL-SDR devices (V3 and V4) have gained popularity among radio amateurs because of their very low cost and rich features. A basic system may consist of a USB based RTL-SDR device (dongle) with a suitable antenna, a Raspberry Pi 5 computer, a USB based external audio input-output adapter, and software installed on the Raspberry Pi 5 computer. With such a modest setup, it is possible to receive signals from around 24 MHz to over 1.7 GHz.
This book is aimed at amateur radio enthusiasts and electronic engineering students, as well as at anyone interested in learning to use the Raspberry Pi 5 to build electronic projects. The book is suitable for both beginners through experienced readers. Some knowledge of the Python programming language is required to understand and eventually modify the projects given in the book. A block diagram, a circuit diagram, and a complete Python program listing is given for each project, alongside a comprehensive description.
The following popular RTL-SDR programs are discussed in detail, aided by step-by-step installation guides for practical use on a Raspberry Pi 5:
SimpleFM
GQRX
SDR++
CubicSDR
RTL-SDR Server
Dump1090
FLDIGI
Quick
RTL_433
aldo
xcwcp
GPredict
TWCLOCK
CQRLOG
klog
Morse2Ascii
PyQSO
Welle.io
Ham Clock
CHIRP
xastir
qsstv
flrig
XyGrib
FreeDV
Qtel (EchoLink)
XDX (DX-Cluster)
WSJT-X
The application of the Python programming language on the latest Raspberry Pi 5 platform precludes the use of the programs in the book from working on older versions of Raspberry Pi computers.
Met de Raspberry Pi M.2 HAT+ kunt u M.2-randapparatuur, zoals NVMe-schijven en AI-versnellers, aansluiten op de PCIe 2.0-interface van Raspberry Pi 5, en ondersteunt snelle (tot 500 MB/s) gegevensoverdracht naar en van NVMe-schijven en andere PCIe-accessoires.
Raspberry Pi M.2 HAT+ ondersteunt apparaten met de M.2 M key edge-connector, in de 2230- en 2242-vormfactoren. Hij kan tot 3 A leveren aan aangesloten M.2-apparaten.
Kenmerken
Ondersteunt single-lane PCIe 2.0-interface (piekoverdrachtssnelheid van 500 MB/s)
Ondersteunt apparaten die de M.2 M Key Edge-connector gebruiken
Ondersteunt apparaten met de 2230- of 2242-vormfactor
Kan tot 3 A leveren aan aangesloten M.2 apparaten
Stroom- en activiteits-LED's
Inbegrepen
1x Raspberry Pi 5 M.2 HAT+
1x Lintkabel
1x GPIO-stapelheader
4x Afstandhouders
8x Schroeven
Downloads
Datasheet
Schematics
Assembly instructions
