Projecten met Arduino, ESPHome, Home Assistant en Raspberry Pi & Co. Dit e-book bevat verschillende voorbeeldprojecten, te beginnen met een inleiding tot elektronica. Het legt ook uit hoe je Home Assistant installeert op een Raspberry Pi, hoe je binnenklimaatsensoren gebruikt voor temperatuur en vochtigheid, hoe je het MQTT-protocol en andere interfaces implementeert, en hoe je ESPHome gebruikt om sensoren en actuatoren te integreren in Home Assistant. Talrijke video tutorials vullen het boek aan. The book begins with an introduction to electrical engineering. You will learn the basics of voltage, current, resistors, diodes and transistors. Arduino and microcontrollers A complete section is dedicated to the Arduino Uno. You will get to know the structure, write your first programs and work on practical examples. Home Assistant and automation You will learn how to set up Home Assistant on a Raspberry Pi and how to use automations, scenes and devices. In addition, Zigbee, MQTT and ESP-NOW – important technologies for home automation – will be discussed. ESP8266, ESP32 and ESP32-CAM The popular ESP microcontrollers are covered in detail. A theoretical introduction is followed by practical projects that show you how to get the most out of these devices. Sensors and actuators The book explains the functionality and application of numerous sensors such as temperature and humidity sensors, motion detectors and RFID readers. For actuators, stepper motors, e-ink displays, servo motors and much more are covered. There are practical application examples for all devices. ESPHome This chapter shows you how to integrate sensors and actuators into Home Assistant without any programming effort. You will be guided step by step through the setup with ESPHome. LEDs and lighting technology In this chapter, you will learn about different types of LEDs and how they can be used. The basics of lighting technology are also explained. Node-RED A whole chapter is dedicated to Node-RED. You will learn the basics of this powerful tool and be guided step by step through its setup and use. Integrated Circuits (ICs) In electronics, there are numerous ICs that make our lives easier. You will get to know the most important ones and apply your knowledge in practical projects. Professional programming Advanced topics such as the correct use of buttons, the use of interrupts and the use of an NTP server for time synchronisation are covered in detail in this chapter. Downloads GitHub

Lees meer minder

Analoge schakelingen, sensors en microcontrollersElektronica is spannend. Het is een hobby die zowel leuk als leerzaam is. Het stelt je in staat om thuis of op het werk nieuwe en nuttige vaardigheden te leren. Een ervaren elektronicus ontwerpt zijn eigen schakelingen, en brengt zijn projecten tot leven. Maar voordat je zover bent, moet je eerst de basis onder de knie krijgen. Daarom brengt dit boek een groot aantal inleidende artikelen samen die in het elektronicatijdschrift Elektor zijn gepubliceerd. Het is je metgezel bij het leerproces in de wereld van de elektronica.Het begint allemaal met analoge elektronica. Je zult de eenvoudigste componenten en circuits ontdekken om te begrijpen hoe ze werken, hoe ze op elkaar inwerken en de mogelijke problemen. De beste manier om vooruitgang te boeken is door echte experimenten uit te voeren, want theorie is niet genoeg. Dit boek begeleid je in een groot aantal praktische projecten voor beginners. Door ze te maken, doe je veel ervaring en kennis op.Het tweede deel van het boek neemt je mee in de wereld van de digitale elektronica. De auteur bespreekt het gebruik van microcontrollers. Taken die voorheen werden uitgevoerd door discrete componenten of conventionele geïntegreerde schakelingen worden nu uitgevoerd door microcontrollers. De programmeertaal BASCOM, maar ook platforms als Arduino, BBC micro:bit en andere, maken dit leerproces veel gemakkelijker. Dit boek beschrijft in detail vele toepassingen van microcontrollers, die betaalbaar zijn voor de beginner. Hier gaan programmeren en solderen hand in hand!

Lees meer minder

Analogue Electronics and Microcontrollers ProjectsHobbyist electronics can be a fun way to learn new skills that can be helpful to your career. Those who understand the basics of electronics can design their own circuits and projects. However, before you run, you need to learn to walk.It all starts with analogue electronics. You should be familiar with the simple components and circuits and understand their basic behaviors and the issues you may encounter. The best way to do this is through real experiments. Theory alone is not enough. This book offers a large number of practical entry-level circuits, with which everyone can gain the basic experience.Through the widespread introduction of microcontrollers, a new chapter in electronics has begun. Microcontrollers are now performing more and more tasks that were originally solved using discrete components and conventional ICs. Starting out has become easier and easier thanks to platforms including Bascom, Arduino, micro:bit. The book introduces numerous manageable microcontroller applications. It’s now a case of less soldering and more programming.

Lees meer minder

In Elektronica Kunst & Kunde worden alle onderwerpen behandeld die ook in standaard elektronica-leerboeken aan de orde komen, plus een groot aantal belangrijke maar vaak veronachtzaamde zaken. In dit tweede deel aandacht voor onder meer de volgende onderwerpen: phase-locked loop-schakelingen, opto-elektronica, busschakelingen, capacitieve belasting, bekabeling, interfacing timing, naaldpulsen, klokvertraging, monostabiele multivibratoren de IBM-PC en de Intel-fanilie, RS232-kabels, seriële poorten, ASCII, modems, SCSI, IPI, GPIB, parallele poorten, local-area-networks de 68000-microprocessorfamilie, perifere LSI-chips, geheugen, programmeerbare instrumenten prototypering, het ontwerpen van printplaten, wire-wrap-technieken, CAD/CAM technieken, de bouw van schakelingen HF-modules, vereenvoudigd ontwerp van HF-versterkers en high-speed schakelaars batterijen, accu's en zonnecellen; micropower-regelaars, -opamps en -microprocessoren methoden om de bandbreedte te beperken, middeling van signalen, lock-in versterkers, pulshoogte-analyse, 'multichannel-scaling'

Lees meer minder

Specifications A4 (210 x 297 mm) squared-grid spiral-bound notebook with watermark breadboards 158 pages, card covers. The book also includes Microcontroller programming cheat sheet Common circuits and calculations Pinouts Resistor color codes ASCII table

Lees meer minder

At long last, here is the thoroughly revised and updated third edition of the hugely successful The Art of Electronics. It is widely accepted as the best single authoritative book on electronic circuit design.In addition to new or enhanced coverage of many topics, the third edition includes 90 oscilloscope screenshots illustrating the behavior of working circuits, dozens of graphs giving highly useful measured data of the sort that is often buried or omitted in datasheets but which you need when designing circuits, and 80 tables (listing some 1650 active components), enabling intelligent choice of circuit components by listing essential characteristics (both specified and measured) of available parts.The new Art of Electronics retains the feeling of informality and easy access that helped make the earlier editions so successful and popular. It is an indispensable reference and the gold standard for anyone, student or researcher, professional or amateur, who works with electronic circuits. Over 450,000 copies sold of first and second editions The leading practical guide to circuit design Fully up to date and packed with valuable advice About the authorsPaul Horowitz is a Research Professor of Physics and of Electrical Engineering at Harvard University, where in 1974 he originated the Laboratory Electronics course from which emerged The Art of Electronics. In addition to his work in circuit design and electronic instrumentation, his research interests have included observational astrophysics, x-ray and particle microscopy, and optical interferometry. He is one of the pioneers of the search for intelligent life beyond Earth (SETI). He is the author of some 200 scientific articles and reports, has consulted widely for industry and government, and is the designer of numerous scientific and photographic instruments.Winfield Hill is by inclination an electronics circuit-design guru. After dropping out of the Chemical Physics graduate program at Harvard University, and obtaining an EE degree, he began his engineering career at Harvard’s Electronics Design Center. After 7 years of learning electronics at Harvard he founded Sea Data Corporation, where he spent 16 years designing instruments for Physical Oceanography. In 1988 he was recruited by Edwin Land to join the Rowland Institute for Science. The institute subsequently merged with Harvard University in 2003. As director of the institute’s Electronics Engineering Lab he has designed some 500 scientific instruments. Recent interests include high-voltage RF (to 15kV), high-current pulsed electronics (to 1200A), low-noise amplifiers (to sub-nV and pA), and MOSFET pulse generators.

Lees meer minder

Elektronica moeilijk? De titel van dit boek geeft het antwoord! In deze 3-in-1-band wordt de elektronica vanuit de praktijk benaderd. Dat wil zeggen veel praktijk in de vorm van experimenten en een minimum aan theorie. Zo raakt u stap voor stap vertrouwd met de behandelde onderwerpen. Daarbij ontstaan gaandeweg ook een flink aantal praktisch bruikbare schakelingen. Het gaat bij de elektronicahobby tenslotte om het bouwen of uitdenken van allerlei praktische of leuke schakelingen. Aan het eind van elk deel is een aanhangsel opgenomen met aanvullende informatie en de gegevens van een groot aantal elektronische componenten, zodat na dit boek ook eigen ideeën en experimenten kunnen worden aangepakt. In deze 3-in-1-band zijn de eerste drie delen uit de serie “Elektronica echt niet moeilijk” samengevoegd: Deel 1: experimenten met gelijkstroom Deel 2: experimenten met wisselstroom Deel 3: experimenten met digitale techniek

Lees meer minder

Êtes-vous curieux de connaître vos débuts et l'électronique sans sauvegarder votre début ? Est-ce fiable d'explorer l'internet qui regorge d'explications et de schémas d'origine inconnue ? Que diriez-vous d'un livre avec des montages simples ou d'un livre avec un livre sur les compositions électroniques ? Fin pédagogue, l'auteur de ce livre écrit pour les débutants dans un style inédit, et répond d'abord aux questions achetées prosaïques du néophyte : quel fer à souder ? Un multimètre de 5 ? peut-il suffire ? Un oscilloscope est toujours indispensable ? Peut-on installer sans montage sans fumer de cigarette ? Et bien d'autres interrogations que trop de livres laissent en suspens. Rémy Mallard démystifie l'électronique en n'utilisant que ce qu'il vous faut de théorie pour aborder la pratique sans risque de faire de trop grosses bêtes. Apprenz à l'identifiant des compositions et au lancer également au récupérateur, au testeur et au ranger. En fonction de votre emploi du temps, choisissez vos outils et vos options d'installation préférées. Rémy signale les pratiques à éviter. Il a beaucoup d'expérience et connaît plein d'astuces. La méthode de réalisation, sont des montages simples et ludiques, réalisables sur des plaques d'expérimentation sans soudure : sirène, orgue, chenillard, interrupteur photosensible, thermomètre, alarme, générateur de picotements, indicateur de liquide, clignotant à vitesse « photo dépendance », indicateur de fenêtre programmable, minute de pré-extinction, style chenillard K2000, gradateur de lumière infrarouge. Après trente ans de pratique de l'électronique aussi bien professionnel qu'amateur, l'auteur, resté l'éternel débutant qui réalisait lu-même son premier montage dès l'âge de dix ans, partage sa soif d'apprendre. Attention, c'est contagieux.

Lees meer minder

The Art of Electronics: The x-Chapters expands on topics introduced in the best-selling third edition of The Art of Electronics, completing the broad discussions begun in the latter. In addition to covering more advanced materials relevant to its companion, The x-Chapters also includes extensive treatment of many topics in electronics that are particularly novel, important, or just exotic and intriguing. Think of The x-Chapters as the missing pieces of The Art of Electronics, to be used either as its complement, or as a direct route to exploring some of the most exciting and oft-overlooked topics in advanced electronic engineering. This enticing spread of electronics wisdom and expertise will be an invaluable addition to the library of any student, researcher, or practitioner with even a passing interest in the design and analysis of electronic circuits and instruments. You'll find here techniques and circuits that are available nowhere else. An important addition to The Art of Electronics literature, this book provides the space to explore key topics in detail, in a way that wasn't possible in the main volume Covers topics ranging from specialized tables, such as high-speed VFB and CFB op-amps to JFETs, fast LED pulsers and transient voltage protection Can be used separately as an advanced standalone book or as an addition to the main volume

Lees meer minder

Er zijn talloze diepgravende elektronica-leerboeken op de markt. We noemen er hier slechts één: ‘The Art of Electronics’, dat onder de titel ‘Elektronica, kunst en kunde’ in vier delen bij Elektor is verschenen. Wie echter elektronicakennis voor “dagelijks gebruik” wil hebben, zit op zo’n wetenschappelijk verantwoorde verhandeling waarschijnlijk helemaal niet te wachten. Laat staan op een beschrijving van de meest exotische componenten of elke denkbare variant van een principiële schakeling.Indien dit ook voor u geldt, dan is dit boek voor u bestemd: voor de middelbare scholier en voor de hobbyist die zich meer wil verdiepen in de elektronica. En dus voor iedereen die een korte, begrijpelijke en bovenal betaalbare inleiding tot dit interessante vakgebied wenst. Deze ‘Basiscursus Elektronica’ maakt u vertrouwd met de analoge (laagfrequent-)techniek, letterlijk de basis van alle elektronica.

Lees meer minder

A Hands-On Lab Course This introduction to circuit design is unusual in several respects. First, it offers not just explanations, but a full course. Each of the twenty-five sessions begins with a discussion of a particular sort of circuit followed by the chance to try it out and see how it actually behaves. Accordingly, students understand the circuit's operation in a way that is deeper and much more satisfying than the manipulation of formulas. Second, it describes circuits that more traditional engineering introductions would postpone: on the third day, we build a radio receiver; on the fifth day, we build an operational amplifier from an array of transistors. The digital half of the course centers on applying microcontrollers, but gives exposure to Verilog, a powerful Hardware Description Language. Third, it proceeds at a rapid pace but requires no prior knowledge of electronics. Students gain intuitive understanding through immersion in good circuit design. The course is intensive, teaching electronics in day-at-a-time practical doses so that students can learn in a hands-on way. The integration of discussion of design with a chance to try the circuits means students learn quickly. The course has been tried and tested, and proven successful through twenty-five years of teaching. The book is practical: it avoids mathematics and mathematical arguments and even includes a complete list of parts needed in the laboratory exercises, including where and how to buy them. The much-anticipated new edition of 'Learning the Art of Electronics' is here! It defines a hands-on course, inviting the reader to try out the many circuits that it describes. Several new labs (on amplifiers and automatic gain control) have been added to the analog part of the book, which also sees an expanded treatment of meters. Many labs now have online supplements. The digital sections have been rebuilt. An FPGA replaces the less-capable programmable logic devices, and a powerful ARM microcontroller replaces the 8051 previously used. The new microcontroller allows for more complex programming (in C) and more sophisticated applications, including a lunar lander, a voice recorder, and a lullaby jukebox. A new section explores using an Integrated Development Environment to compile, download, and debug programs. Substantial new lab exercises, and their associated teaching material, have been added, including a project reflecting this edition's greater emphasis on programmable logic. Online resources including online chapters, teaching materials and video demonstrations can be found at: www.LearningTheArtOfElectronics.com Downloads Table of Contents

Lees meer minder

Build Trust and Convert Buyers with Technical Content Research shows that this analytical, skeptical buyer conducts a great deal of independent research before engaging with vendors. Companies that share expertise through high-quality content on a consistent basis are not only seen as trusted resources, they also spend less per lead and achieve greater pipeline efficiency. Content Marketing, Engineered guides you through the key steps in creating content to inform, educate, and help your technical buyers on their journey to purchase and beyond. By the time you reach the last page, you’ll be familiar with the entire end-to-end content marketing process, from planning and writing to publishing, promoting, and measuring the performance of your content.
