Integral Light Source, High Precision and Uniformity
The self-developed integral light source adopts the reflection & refraction to make the light intensity distribution of the whole screen uniform, and each dimension of the model with consistent accuracy.
Integral Light Source vs Matrix Light Source
Integral light source: It is composed of 12 lamp beads, and each lamp bead e is composed of 4 light-emitting chips, the uniformity of light source energy can reach more than 80%. When the individual lamp beads are attenuated, the uniformity of the printed model e is not affected.
Ordinary light source: It consists of many ultraviolet lamp beads evenly arranged in a row. The light intensity of the lamp bead splicing area is uneven, and the lamp bead damage has a greater impact on the uniformity of the printed model.
Wi-Fi/APP Remote Control
- Creality Cloud APP for monitor printing progress, adjust the printing settings, Start/Stop prints.
- Built-in Wi-Fi allows one-click upgrades to the firmware.
Double Heat Dissipation, Efficient Purification
- Specially designed dual heat dissipation system, precise and intelligent control to detect the heat source, and quickly evaporate heat.
- Activated carbon air filtration system to reduce odor emission and optimize printing experience.
|LCD pixel ||3840 x 2400 |
|LCD screen ||8.9' monochrome |
|Light source ||Integral Light Source |
|Printing size ||192 x 120 x 200 mm |
|XY-axis precision ||0.05 mm |
|Printing speed ||1-4s/layer |
|Layer thickness ||0.01-0.2 mm |
|Interaction screen ||5' color touch screen |
|Material ||405 nm UV Resin |
|Auto-leveling ||Easy manual leveling |
|Input power ||100-240 V |
|Machine size ||330 x 301 x 572 mm |
|Machine weight ||10.6 kg |
