Pimoroni Pico LiPo is powered and programmable via USB-C and comes with 16 MB of QSPI (XiP) flash. With the Qwiic/STEMMA QT connector you can hook up a whole host of different sensors and breakouts, and a debug connector for if you want to do your programming using a SWD debugger. There is an on/off button and a BOOTSEL button, which can also be used as a user switch.Pimoroni Pico LiPo also has onboard LiPo/LiIon battery management – the inbuilt charging circuitry means charging your battery is as easy as plugging your Pimoroni Pico Lipo in via USB. Two indicator LEDs connected to the battery circuit keep you informed of on/off state and charging status and it's compatible with any of our LiPo, LiIon and high capacity LiPo batteries.Programmable with C++, MicroPython or CircuitPython, Pimoroni Pico LiPo is the perfect powerhouse for your portable projects.Features Powered by RP2040 Dual ARM Cortex M0+ running at up to 133 Mhz 264 kB of SRAM 16 MB of QSPI flash supporting XiP MCP73831 charger with 215 mA charging current (datasheet) XB6096I2S battery protector (datasheet) USB-C connector for power, programming, and data transfer 4 pin Qw-ST (Qwiic / STEMMA QT) connector 3 pin debug connector (JST-SH) 2-pole JST PH battery connector, with polarity marked on the board Switch for basic input (doubles up as DFU select on boot) Power button Power, charging and user LED indicators On-board 3V3 regulator (max regulator current output 600mA) Input voltage range 3 - 5.5 V Compatible with Raspberry Pi Pico add-ons Measurements: approx 53 x 21 x 8 mm (L x W x H, including connectors) Downloads CircuitPython Getting started with CircuitPython guide

Lees meer minder

Je zou Pirate Audio Headphone Amp kunnen gebruiken om een nette, zakformaat speler te bouwen voor lokale audiobestanden (MP3, FLAC, etc) of voor het streamen van muziek van online diensten zoals Spotify. Om je op weg te helpen heeft Pimoroni plugins gebouwd voor Mopidy waarmee je prachtige album art kunt weergeven, je tracks kunt afspelen/pauzeren en het volume kunt regelen. De DAC en hoofdtelefoonversterker geven je heldere digitaal versterkte audio via je hoofdtelefoon met kabel. Pirate Audio is een reeks van alles-in-een audio boards voor Raspberry Pi, met hoge kwaliteit digitale audio, prachtig heldere IPS displays voor album art, tactiele knoppen voor playback controle, en een aangepaste Pirate Audio software en installer om het opzetten van dit allemaal een fluitje van een cent te maken.Functies Versterkte digitale audio (24-bit / 192KHz) over I2S PAM8908 hoofdtelefoonversterker chip Low-gain / high-gain schakelaar (high-gain verhoogt met 12dB) PCM5100A DAC-chip 3.5mm stereo aansluiting 1,3' IPS-kleurenscherm (240x240px) (ST7789 driver) Vier tactiele knoppen Mini HAT-formaat bord Volledig gemonteerd Compatibel met alle 40-pin header Raspberry Pi modellen Afmetingen: 65x30.5x9.5mm SoftwareDe Pirate Audio software en installer installeert de Python bibliotheek voor de LCD, configureert de I2S audio en SPI, en installeert vervolgens Mopidy en de aangepaste Pirate Audio plugins om album art en track info weer te geven, en om de knoppen te gebruiken voor playback control.Hier ziet u hoe u aan de slag kunt: Stel een SD-kaart in met de laatste versie van Raspberry Pi OS. Gebonden met Wi-Fi of een bekabeld netwerk. Open een terminal en typ het volgende:git clone https://github.com/pimoroni/pirate-audiocd pirate-audio/mopidysudo ./install.sh Reboot uw Pi Downloads PAM8908 Datasheet PCM5100A-gegevensblad Pirate Audio software

Lees meer minder

Pico Breakout Garden Base sits underneath your Pico and lets you connect up to six of our extensive selection of Pimoroni breakouts to it. Whether it's environmental sensors so you can keep track of the temperature and humidity in your office, a whole host of little screens for important notifications and readouts, and, of course, LEDs. Scroll down for a list of breakouts that are currently compatible with our C++/MicroPython libraries!As well as a labelled landing area for your Pico, there's also a full set of broken out Pico connections, in case you need to attach even more sensors, wires, and circuitry. We've thrown in some rubber feet to keep the base nice and stable and to stop it from scratching your desk, or there are M2.5 mounting holes at the corners so that you can bolt it onto a solid surface if you prefer.The six sturdy black slots are edge connectors that connect the breakouts to the pins on your Pico. There's two slots for SPI breakouts, and four slots for I²C breakouts. Because I²C is a bus, you can use multiple I²C devices at the same time, providing they don't have the same I²C address (we've made sure that all of our breakouts have different addresses, and we print them on the back of the breakouts so they're easy to find).As well as being a handy way to add functionality to your Pico, Breakout Garden is also very useful for prototyping projects without the need for complicated wiring, soldering, or breadboards, and you can grow or change up your setup at any time.Features Six sturdy edge-connector slots for breakouts 4x I²C slots (5 pins) 2x SPI slot (7 pins) Landing area with female headers for Raspberry Pi Pico 0.1” pitch, 5 or 7 pin connectors Broken-out pins Reverse polarity protection (built into breakouts) 99% assembled – just need to stick on the feet! Compatible with Raspberry Pi Pico

Lees meer minder

Pico Display lets you turn a Pico into a compact user interface device for a bigger project, capable of giving instructions, displaying readouts and even incorporating elaborate nested menus. If you'd rather use your Pico as a standalone device you could make a little rotating slideshow of images, display beautiful graphs from sensor data or build your own Tamagotchi or matchbox sized text adventure game.Features 1.14” 240x135 pixel IPS LCD screen 4 x tactile buttons RGB LED Pre-soldered female headers for attaching to Pico Compatible with Raspberry Pi Pico. Fully assembled No soldering required (as long as your Pico has header pins attached). Dimensions: approx 53 x 25 x 9 mm (L x W x H) Screen usable area: approx 25 x 15 mm (L x W) C/C++ and MicroPython libraries

Lees meer minder

This board is an all-digital conversion of Raspberry Pi's VGA reference design, great for if you want to start hacking on video and/or audio output from a Raspberry Pi Pico and piping it straight into a modern monitor.Features HDMI connector PCM5100A DAC for line out audio over I²S (datasheet) SD card slot Reset button Socket headers to install your Raspberry Pi Pico Three user-controllable switches Rubber feet Compatible with Raspberry Pi Pico No soldering required (as long as your Pico has header pins attached) Programmable with C/C++ Note: Raspberry Pi Pico is not included. Your Pico will need to have pin headers soldered to it (with the pins pointing downwards) to attach to our add-on boards.Downloads Schematic GitHub

Lees meer minder

We've incorporated tinkering essentials like a mini breadboard, motor drivers, ADC inputs, a built in speaker, general purpose inputs/outputs, switches, and two Breakout Garden slots so you can add on a couple of breakouts.We've also managed to fit in a vibrant 240x240 IPS LCD screen with four tactile buttons so you can easily monitor and control what your project is doing. It's all wrapped up in a nice, sturdy baseboard with a pleasingly compact footprint which won't involve nearly as many trailing wires as if you were experimenting with a traditional breadboard setup.Our comprehensive MicroPython and C++ libraries will let you control every aspect of the board like a digital maestro. It's great for beginners and advanced users.Features Pico Explorer Base Piezo speaker 1.54' IPS LCD screen (240x240) Four user-controllable switches Two Half-Bridge motor drivers (with over current indicator LED) Easy access GPIO and ADC pin Headers Two Breakout Garden I²C sockets Mini breadboard Rubber feet Compatible with Raspberry Pi Pico No soldering required (as long as your Pico has header pins attached). Dimensions: approx 117 x 63 x 20 mm (L x W x H, assembled) C/C++ and MicroPython libraries Schematic

Lees meer minder

Struggling to choose which Pico add-on to go for? Pico Omnibus lets you plug in two Pico Packs or Bases at once, or you can use the extra set of male GPIO pins to easily attach other devices, jumper wires or circuitry – very useful for prototyping. We've added useful labels to all three sets of connectors, so you can be sure that all those lovely wires are going to the right places. We've also thrown in some little feet to keep everything solid.Features One landing area with labelled female headers for attaching to your Pico. Two landing areas with labelled (mirrored) male headers for attaching add-ons. 4x rubber feet Compatible with Raspberry Pi Pico. 99% assembled – just need to stick on the feet! Fully assembled. No soldering required. Dimensions: approx 94 x 52 x 12 mm (L x W x H, including headers)

Lees meer minder

With a 6x20 grid of 2.54 mm spaced holes for easy soldering and labelled Pico pins so you know what's what, Pico Proto is perfect for when you're happy with your breadboard project and want to give it a secure, smart and compact long-term home. Pico Proto doesn't come with any headers attached, so you will need to either solder it directly to your Pico's male header pins (for a permanent, but super slim sandwich) or solder it to some female header. Features 40 2.54 mm spaced holes for attaching to your Pico. 120 2.54 mm spaced holes (6x20 grid) for attaching other things Compatible with Raspberry Pi Pico. Dimensions: approx 51 x 25 x 1 mm (L x W x H)

Lees meer minder

The Unicorn Pack fits nicely on the back of your Pico - with a tidy 7x16 matrix (that's 112 RGB LEDs!) it's surely the fanciest backpack going. The four tactile buttons can be used to switch between modes, as controls for simple games, or adjusting brightness. It's possible to control the colour and brightness of each LED individually so you can use it to display animations, text, simple images, and more. Make a mini photo FX lamp, a smart status light for Zoom, use it to display colourful scrolling messages on your fridge, or just enjoy some pretty animations. Features 16x7 matrix of RGB LEDs (112 total) Individual colour/brightness control of each LED 4 x tactile buttons Pre-soldered female headers for attaching to Pico Compatible with Raspberry Pi Pico. Fully assembled No soldering required (as long as your Pico has header pins attached). Dimensions: approx 62mm x 25mm x 10mm (L x W x H, including headers and buttons) C/C++ and MicroPython libraries

Lees meer minder

Based on the reference design by Raspberry Pi, our Pimoroni Pico VGA Demo Base is a great way to start experimenting with Raspberry Pi Pico/RP2040. It's the perfect way to demo of some of the fun things you can achieve with the RP2040 microcontroller such as generating a solid VGA output without taxing the CPU at all! Amaze your friends by showing them you still own a D-sub cable! Bask in the glory of 15-bit analog video! Get teary eyed over the warm, authentic, RC filtered PWM audio! This board will run the various video example programs that Raspberry Pi have put together to demonstrate features of the RP2040.Features 15-pin VGA (D-sub) connector PCM5100A DAC for line out audio over I²S (datasheet) PWM audio output SD card slot Reset button Female headers to install your Raspberry Pi Pico Three user-controllable switches Rubber feet Compatible with Raspberry Pi Pico No soldering required (as long as your Pico has header pins attached) Programmable with C/C++

Lees meer minder

Raspberry Pi Pico Wireless Pack attaches to the back of your Pico and uses an ESP32 chip to let your Pico connect to 2.4 GHz wireless networks and transfer data. There's a microSD card slot for if you want to store lots of data locally as well as a RGB LED (for status updates) and a button (useful for things like enabling/disabling Wi-Fi).Great for quickly adapting an existing Pico project to have wireless functionality, Raspberry Pi Pico Wireless Pack would come in handy for sending sensor data into home automation systems or dashboards, for hosting a web page from a matchbox or for letting your Pico interact with online APIs.Features ESP32-WROOM-32E module for wireless connectivity (connected via SPI) (datasheet) 1x tactile button RGB LED Micro-SD card slot Pre-soldered female headers for attaching your Raspberry Pi Pico Fully assembled No soldering required (as long as your Pico has header pins attached) Compatible with Raspberry Pi Pico Dimensions: approx 53 x 25 x 11 mm (L x W x H, including headers and components) C++ and MicroPython libraries

Lees meer minder

Een meteorologisch georiënteerde Raspberry Pi HAT ontworpen om het aansluiten van diepe L sensoren een makkie te maken (of een bui, of een storm).Weather HAT is een alles-in-een oplossing voor het aansluiten van klimaat- en milieusensoren op een Raspberry Pi. Het heeft een helder 1,54' LCD-scherm en vier knoppen voor inputs. De onboard sensoren kunnen temperatuur, vochtigheid, druk en licht meten. Met de stevige RJ11 connectoren kun je gemakkelijk wind- en regensensoren aansluiten. Het werkt met elke Raspberry Pi met een 40-pin header.U kunt het buiten installeren in een geschikte weerbestendige behuizing en er draadloos verbinding mee maken - de gegevens lokaal opslaan of doorsturen naar Weather Underground, een MQTT-makelaar of een cloudservice zoals Adafruit IO. Als alternatief kunt u uw weer Pi binnen huisvesten en draden naar uw deep L sensoren buiten leiden - gebruikmakend van het mooie scherm om uitlezingen weer te geven.Features 1,54' IPS LCD-scherm (240 x 240) Vier door de gebruiker te bedienen schakelaars BME280 temperatuur, druk, vochtigheid sensor (datasheet) LTR-559 licht- en nabijheidssensor (datasheet) Nuvoton MS51 microcontroller met ingebouwde 12-bit ADC (datasheet) RJ11-connectoren voor aansluiting van wind- en regensensoren (optioneel) HAT-formaat bord Volledig gemonteerd Compatibel met alle 40-pin header Raspberry Pi modellen Downloads Python-bibliotheek Schema Inbegrepe Weer HAT 2x 10 mm afstandsbedieningen

Lees meer minder

De unPhone is een open-source IoT-ontwikkelplatform dat wordt aangedreven door de ESP32S3 microcontroller. Het beschikt over geïntegreerde LoRa, Wi-Fi en Bluetooth connectiviteit, een touchscreen en een LiPo batterij en biedt een robuuste en veelzijdige oplossing voor IoT-ontwikkeling. De compatibiliteit met Adafruit's FeatherWing standaard maakt eenvoudige uitbreiding mogelijk, waardoor het een ideale keuze is voor opvoeders, makers en ontwikkelaars die op zoek zijn naar een flexibel en gebruiksvriendelijk platform. Kenmerken ESP32S3-microcontroller (met 8 MB flash en 8 MB PSRAM) LoRaWAN licentievrije radiocommunicatie (plus de uitstekende wifi- en Bluetooth-ondersteuning van de ESP32) Capacitief LCD-touchscreen van 3,5 inch (320 x 480) voor eenvoudige foutopsporing en het maken van een gebruikersinterface IR-LED's voor het heimelijk uitschakelen van de café-tv LiPo-batterij van 1200 mAh met opladen via USB-C Trilmotor voor meldingen Kompas/versnellingsmeter Een robuuste behuizing SD-kaartsleuf Aan/uit- en resetknoppen Programmeerbaar in C++ of CircuitPython Uitbreidingsbord dat twee Featherwing-sockets en een ruimte voor prototypen ondersteunt Open source firmware compatibel met de Arduino IDE, PlatformIO en Espressif's IDF ontwikkelingsframework Inbegrepen unPhone (gemonteerd) Uitbreidingsbord FPC-kabel (om de uitbreidingskaart aan de unPhone te koppelen) Zelfklevende bevestigingen voor de uitbreidingskaart Code-voorbeelden C++ library Kick the tyres on everything in the box The main LVGL demo CircuitPython Support forum Textbook (especially chapter 11)
