GreatFET One is a hardware hacker’s best friend. With an extensible, open source design, two USB ports, and 100 expansion pins, GreatFET One is your essential gadget for hacking, making, and reverse engineering. By adding expansion boards called neighbors, you can turn GreatFET One into a USB peripheral that does almost anything.Whether you need an interface to an external chip, a logic analyzer, a debugger, or just a whole lot of pins to bit-bang, the versatile GreatFET One is the tool for you. Hi-Speed USB and a Python API allow GreatFET One to become your custom USB interface to the physical world.Features Serial protocols: SPI, I²C, UART, and JTAG Programmable digital I/O Analog I/O (ADC/DAC) Logic analysis Debugging Data acquisition Four LEDs Versatile USB functions High-throughput hardware-assisted streaming serial engine Downloads Documentation GitHub

Lees meer minder

Opera Cake is een antenne-schakelboard voor HackRF One dat wordt geconfigureerd met command-line software, zowel handmatig of met een automatische poortschakeling op basis van frequentie of tijd. Het heeft twee primaire poorten, elk verbonden met een van de acht secundaire poorten, en is geoptimaliseerd voor gebruik als een paar 1x4 switches of als een enkele 1x8 switch. Wanneer HackRF One wordt gebruikt om te zenden, kan Opera Cake automatisch zijn uitgang naar de juiste zendantennes leiden, evenals eventuele externe filters, versterkers, enz. Er zijn geen wijzigingen nodig in de bestaande SDR software, maar volledige controle vanaf de host is mogelijk. Opera Cake verbetert ook het gebruik van de HackRF One als spectrum analyzer over het gehele frequentiebereik van 1 MHz tot 4 GHz. Het schakelen van antennes werkt met de bestaande hackrf_sweep functie, die het hele afstembereik in minder dan een seconde kan doorlopen. Automatisch schakelen halverwege de sweep maakt het gebruik van meerdere antennes mogelijk bij het sweepen van een groot frequentiebereik. Downloads Documentatie GitHub

Lees meer minder

YARD Stick One (Yet Another Radio Dongle) is a sub-1 GHz wireless transceiver IC on a USB dongle. It is based on the Texas Instruments CC1111. YARD Stick One can transmit or receive digital wireless signals at frequencies below 1 GHz. It uses the same radio circuit as the popular IM-Me. The radio functions that are possible by customizing IM-Me firmware are now at your fingertips when you attach YARD Stick One to a computer via USB. Features Half-duplex transmit and receive Official operating frequencies: 300-348 MHz, 391-464 MHz, and 782-928 MHz Unofficial operating frequencies: 281-361 MHz, 378-481 MHz, and 749-962 MHz Modulations: ASK, OOK, GFSK, 2-FSK, 4-FSK, MSK Data rates up to 500 kbps Full-Speed USB 2.0 SMA female antenna connector (50 ohms) Software-controlled antenna port power (max 50 mA at 3.3 V) Low pass filter for elimination of harmonics when operating in the 800 and 900 MHz bands GoodFET-compatible expansion and programming header GIMME-compatible programming test points Open source Downloads Documentation GitHub

Lees meer minder

Deze antenne werkt ook met Arduino MKR FOX 1200 / Ardunio MKR GSM 1400 / Arduino MKR WAN 1300. Antenne-aansluiting: U.FL GSM 433/868/915 MHz

Lees meer minder

Based on PIC microcontrollers and Arduino Every mobile phone includes a GSM/GPRS modem which enables the phone to communicate with the external world. With the help of the GSM modems, users can establish audio conversations and send and receive SMS text messages. In addition, the GPRS modem enables users to connect to the internet and to send and receive large files such as pictures and video over the internet. This book is aimed for the people who may want to learn how to use the GSM/GPRS modems in microcontroller based projects. Two types of popular microcontroller families are considered in the e-book: PIC microcontrollers, and the Arduino. The highly popular mid-performance PIC18F87J50 microcontroller is used in PIC based projects together with a GSM Click board. In addition, the SIM900 GSM/GPRS shield is used with the Arduino Uno projects. Both GSM and GPRS based projects are included in the e-book. The book will enable you to control equipment remotely by sending SMS messages from your mobile phone to the microcontroller, send the ambient temperature readings from the microcontroller to a mobile phone as SMS messages, use the GPRS commands to access the internet from a microcontroller, send temperature readings to the cloud using UDP and TCP protocols and so on. It is assumed that the reader has some basic working knowledge of the C language and the use of microcontrollers in simple projects. Although not necessary, knowledge of at least one member of the PIC microcontroller family and the Arduino Uno will be an advantage. It will also be useful if the user has some knowledge of basic electronics.

Lees meer minder

De GTMEDIA V8 Finder2 is een draagbare satellietmeter die de standaarden DVB-S/S2 en MPEG-2/4 H.264 (8-bit) ondersteunt. Ontworpen voor gebruiksgemak, beschikt hij over een compact formaat, lichtgewicht constructie, gebruiksvriendelijke interface, langere batterijduur en een uitgebreide reeks functies. Deze meter biedt alle essentiële functies die nodig zijn voor een efficiënte installatie en verificatie van digitale satelliet-tv-diensten, of het nu gaat om individuele woningen of eenheden met meerdere woningen. Specificaties Frequentiebereik 950-2150 MHz DC IN 13 V/18 V (max. 350 mA) Display 3,5" HD TFT LCD-scherm (320 x 240) Standaard DVB-S/S2/S2X Batterij Ingebouwde lithiumbatterij van 7,4 V/4000 mAh Afmetingen 95 x 155 x 45 mm Gewicht 450 g Inbegrepen GTmedia V8 Finder 2 USB-kabel Manual

Lees meer minder

This smart plinth lighting automatically switches on and off when you get up at night. The motion sensor sees you get out of bed and the light turns on! There is an illuminated path from bed to toilet. Obstacles on the way to the toilet are immediately visible and tripping hazards are prevented. Scientific research shows that the fear of falling is significantly reduced when using a Guide Light. The LED lighting has a perfect light intensity. The light is subtle enough not to wake you up, but bright enough for a reliable orientation. The Guiding Light is much more than just a night light.

Lees meer minder

Build your own AI microcontroller applications from scratch The MAX78000FTHR from Maxim Integrated is a small development board based on the MAX78000 MCU. The main usage of this board is in artificial intelligence applications (AI) which generally require large amounts of processing power and memory. It marries an Arm Cortex-M4 processor with a floating-point unit (FPU), convolutional neural network (CNN) accelerator, and RISC-V core into a single device. It is designed for ultra-low power consumption, making it ideal for many portable AI-based applications. This book is project-based and aims to teach the basic features of the MAX78000FTHR. It demonstrates how it can be used in various classical and AI-based projects. Each project is described in detail and complete program listings are provided. Readers should be able to use the projects as they are, or modify them to suit their applications. This book covers the following features of the MAX78000FTHR microcontroller development board: Onboard LEDs and buttons External LEDs and buttons Using analog-to-digital converters I²C projects SPI projects UART projects External interrupts and timer interrupts Using the onboard microphone Using the onboard camera Convolutional Neural Network

Lees meer minder

Build your own AI microcontroller applications from scratch The MAX78000FTHR from Maxim Integrated is a small development board based on the MAX78000 MCU. The main usage of this board is in artificial intelligence applications (AI) which generally require large amounts of processing power and memory. It marries an Arm Cortex-M4 processor with a floating-point unit (FPU), convolutional neural network (CNN) accelerator, and RISC-V core into a single device. It is designed for ultra-low power consumption, making it ideal for many portable AI-based applications. This book is project-based and aims to teach the basic features of the MAX78000FTHR. It demonstrates how it can be used in various classical and AI-based projects. Each project is described in detail and complete program listings are provided. Readers should be able to use the projects as they are, or modify them to suit their applications. This book covers the following features of the MAX78000FTHR microcontroller development board: Onboard LEDs and buttons External LEDs and buttons Using analog-to-digital converters I²C projects SPI projects UART projects External interrupts and timer interrupts Using the onboard microphone Using the onboard camera Convolutional Neural Network

Lees meer minder

Ontwikkel audio-, DSP- en motorbesturingsprojecten met Arm Cortex-M7 Het hart van de MIMXRT1010 Development Kit van NXP Semiconductors wordt gevormd door de i.MX RT1010 Crossover MCU met een Arm Cortex-M7 core. Deze processor kan DSP-toepassingen uitvoeren, die veel vermogen en geheugen vragen. Met de populaire MCUXpresso IDE kan men software ontwikkelen voor de dev kit. Tevens wordt een krachtige SDK (Software Development Kit) wordt meegeleverd om sneller programma's te ontwikkelen. De dev kit biedt zeer goede connectiviteit via de audio CODECs, 4-weg hoofdtelefoonaansluiting, externe speaker-aansluiting, microfoon en de Arduino-interface. De dev kit heeft verschillende ingebouwde debug-probes, zodat je je programma's kunt debuggen door rechtstreeks met de MCU te praten. Met behulp van de debugger kun je een programma in één stap doorlopen, onderbrekingspunten invoegen, variabelen bekijken en wijzigen, enzovoort. Met behulp van de MCUXpresso IDE en de SDK worden in het boek veel geteste projecten ontwikkeld met behulp van diverse onderdelen, modules en technologieën, zoals: LED's en LCD's ADC I²C-projecten SPI-projecten UART-projecten Motorbesturing Audio en digitale signaal processor (DSP) Deze bundel bevat: Getting started with the NXP i.MX RT1010 Development Kit Boek (normale prijs: € 34,95) NXP i.MX RT1010 Kit Development Kit Hardware (normale prijs: € 49,95)

Lees meer minder

STmicroelectronics’ wireless IoT & wearable sensor development kit ‘SensorTile.box’ is a portable multi-sensor circuit board housed in a plastic box and developed by STMicroelectronics. It is equipped with a high-performance 32-bit ARM Cortex-M4 processor with DSP and FPU, and various sensor modules, such as accelerometer, gyroscope, temperature sensor, humidity sensor, atmospheric pressure sensor, microphone, and so on. SensorTile.box is ready to use with wireless IoT and Bluetooth connectivity that can easily be used with an iOS or Android compatible smartphone, regardless of the level of expertise of the users. SensorTile.box is shipped with a long-life battery and all the user has to do is connect the battery to the circuit to start using the box. The SensorTile.box can be operated in three modes: Basic mode, Expert mode, and Pro mode. Basic mode is the easiest way of using the box since it is pre-loaded with demo apps and all the user has to do is choose the required apps and display or plot the measured data on a smartphone using an app called STE BLE Sensor. In Expert mode users can develop simple apps using a graphical wizard provided with the STE BLE Sensor. Pro mode is the most complex mode allowing users to develop programs and upload them to the SensorTile.box. This book is an introduction to the SensorTile.box and includes the following: Brief specifications of the SensorTile.box; description of how to install the STE BLE Sensor app on an iOS or Android compatible smartphone required to communicate with the box. Operation of the SensorTile.box in Basic mode is described in detail by going through all of the pre-loaded demo apps, explaining how to run these apps through a smartphone. An introduction to the Expert mode with many example apps developed and explained in detail enabling users to develop their own apps in this mode. Again, the STE BLE Sensor app is used on the smartphone to communicate with the SensorTile.box and to run the developed apps. The book then describes in detail how to upload the sensor data to the cloud. This is an important topic since it allows the sensor measurements to be accessed from anywhere with an Internet connection, at any time. Finally, Pro mode is described in detail where more experienced people can use the SensorTile.box to develop, debug, and test their own apps using the STM32 open development environment (STM32 ODE). The Chapter explains how to upload the developed firmware to the SensorTile.box using several methods. Additionally, the installation and use of the Unicleo-GUI package is described with reference to the SensorTile.box. This PC software package enables all of the SensorTile.box sensor measurements to be displayed or plotted in real time on the PC.

Lees meer minder

STmicroelectronics’ wireless IoT & wearable sensor development kit ‘SensorTile.box’ is a portable multi-sensor circuit board housed in a plastic box and developed by STMicroelectronics. It is equipped with a high-performance 32-bit ARM Cortex-M4 processor with DSP and FPU, and various sensor modules, such as accelerometer, gyroscope, temperature sensor, humidity sensor, atmospheric pressure sensor, microphone, and so on. SensorTile.box is ready to use with wireless IoT and Bluetooth connectivity that can easily be used with an iOS or Android compatible smartphone, regardless of the level of expertise of the users. SensorTile.box is shipped with a long-life battery and all the user has to do is connect the battery to the circuit to start using the box. The SensorTile.box can be operated in three modes: Basic mode, Expert mode, and Pro mode. Basic mode is the easiest way of using the box since it is pre-loaded with demo apps and all the user has to do is choose the required apps and display or plot the measured data on a smartphone using an app called STE BLE Sensor. In Expert mode users can develop simple apps using a graphical wizard provided with the STE BLE Sensor. Pro mode is the most complex mode allowing users to develop programs and upload them to the SensorTile.box. This book is an introduction to the SensorTile.box and includes the following: Brief specifications of the SensorTile.box; description of how to install the STE BLE Sensor app on an iOS or Android compatible smartphone required to communicate with the box. Operation of the SensorTile.box in Basic mode is described in detail by going through all of the pre-loaded demo apps, explaining how to run these apps through a smartphone. An introduction to the Expert mode with many example apps developed and explained in detail enabling users to develop their own apps in this mode. Again, the STE BLE Sensor app is used on the smartphone to communicate with the SensorTile.box and to run the developed apps. The book then describes in detail how to upload the sensor data to the cloud. This is an important topic since it allows the sensor measurements to be accessed from anywhere with an Internet connection, at any time. Finally, Pro mode is described in detail where more experienced people can use the SensorTile.box to develop, debug, and test their own apps using the STM32 open development environment (STM32 ODE). The Chapter explains how to upload the developed firmware to the SensorTile.box using several methods. Additionally, the installation and use of the Unicleo-GUI package is described with reference to the SensorTile.box. This PC software package enables all of the SensorTile.box sensor measurements to be displayed or plotted in real time on the PC.

Lees meer minder

SensorTile.box' is een draagbare multi-sensor print in een plastic doos en ontwikkeld door STMicroelectronics. Deze is uitgerust met een krachtige 32-bits ARM Cortex-M4-processor met DSP en FPU, en verschillende sensormodules, zoals een versnellingsmeter, gyroscoop, temperatuursensor, vochtigheidssensor, luchtdruksensor, microfoon, enzovoort. SensorTile.box is klaar voor gebruik met draadloze IoT- en Bluetooth-connectiviteit die gemakkelijk kan worden gebruikt met een iOS- of Android-compatibele smartphone, ongeacht het expertiseniveau van de gebruiker. SensorTile.box wordt geleverd met een batterij met lange levensduur en het enige wat de gebruiker hoeft te doen is de batterij aan te sluiten op de schakeling om de box te kunnen gebruiken. Inbegrepen sensoren Temperatuur 3-assige versnellingsmeter 3-assige magnetometer 3-assige versnelling & gyroscoop (6-assige traagheid) Vochtigheid Hoogtemeter/Druk Microfoon Meegeleverde randapparatuur Bluetooth Li-Ion oplader DC-DC-converter 500 mAh Li-Ion batterij

Lees meer minder

Deze endoscoopcamera is voorzien van een microlens van 8 mm met een kijkhoek van 170° en 6 verstelbare LED-lampjes voor heldere, high-definition beelden. Het ergonomische handheld-ontwerp maakt bediening met één hand mogelijk, en de semi-flexibele kabel van 2 m navigeert gemakkelijk door smalle ruimtes. Dankzij de IP67-waterdichtheid is de camera ideaal voor natte omgevingen, terwijl de antislip matte behuizing zorgt voor comfort en gebruiksgemak. Het werkt zonder de noodzaak van wifi, telefoons of apps, waardoor het een praktisch hulpmiddel is voor industriële taken zoals loodgieterswerk, autoreparatie en huisonderhoud. Specificaties Display 2,4 inch Resolutie 1920 x 1080 Lensgrootte 8 mm Brandpuntsafstand 3-10 cm Horizontale kijkhoek 170° Afbeeldingsformaat JPEG Licht 6 LED's (instelbaar) Interface USB-C Batterij Ingebouwde lithiumbatterij van 2600 mAh Bedrijfsuren 4-5 uur Kabellengte 2 m Inbegrepen Endoscoopcamera met 2,4-inch LCD-scherm USB-kabel Manual

Lees meer minder

32 new Projects, Practical Examples and Exercises with the Elektor Arduino Nano MCCAB Training Board Electronics and microcontroller technology offer the opportunity to be creative. This practical microcontroller course provides you with the chance to bring your own Arduino projects and experience such moments of success. Ideally, everything works as you imagined when you switch it on for the first time. In practice, however, things rarely work as expected. At that point, you need knowledge to efficiently search for and find the reason for the malfunction. In this book for advanced users, we delve deep into the world of microcontrollers and the Arduino IDE to learn new procedures and details, enabling you to successfully tackle and solve even more challenging situations. With this book, the author gives the reader the necessary tools to create projects independently and also to be able to find errors quickly. Instead of just offering ready-made solutions, he explains the background, the hardware used, and any tools required. He sets tasks in which the reader contributes their own creativity and writes the Arduino sketch themselves. If you don’t have a good idea and get stuck, there is, of course, a suggested solution for every project and every task, along with the corresponding software, which is commented on and explained in detail in the book. This practical course will teach you more about the inner workings of the Arduino Nano and its microcontroller. You will get to know hardware modules that you can use to realize new and interesting projects. You will familiarize yourself with software methods such as ‘state machines,’ which can often be used to solve problems more easily and clearly. The numerous practical projects and exercise sketches are once again realized on the Arduino Nano MCCAB Training Board, which you may already be familiar with from the course book ‘Microcontrollers Hands-on Course for Arduino Starters’, and which contains all the hardware peripherals and operating elements we need for the input/output operations of our sketches. Readers who do not yet own the Arduino Nano MCCAB Training Board can purchase the required hardware separately, or alternatively, build it on a breadboard.

Lees meer minder

The Raspberry Pi is a $35 credit-card sized computer with many applications, such as in desktop computing, audio and video playback, and as a controller in many industrial, commercial and domestic applications. This book is about the Raspberry Pi computer and its use in control applications. The book explains in simple terms, with examples, how to configure the RPi, how to install and use the Linux operating system, how to write programs using the Python programming language and how to develop hardware based projects. The book starts with an introduction to the Raspberry Pi computer and covers the topics of purchasing all the necessary equipment and installing/using the Linux operating system in command mode. Use of the user-friendly graphical desktop operating environment is explained using example applications. The RPi network interface is explained in simple steps and demonstrates how the computer can be accessed remotely from a desktop or a laptop computer. The remaining parts of the book cover the Python programming language, hardware development tools, hardware interface details, and RPi based hardware projects. All the 23 projects given in the book have been tested and are working. The following headings are given for each project: Project title Project description Project block diagram Project circuit diagram Project program description using the Program Description Language (PDL) Complete program listing Description of the program The book is ideal for self-study, and is intended for electronic/electrical engineering students, practising engineers, research students, and hobbyists.
