SoC |
Broadcom BCM2711 |
CPU |
64-bit ARM Cortex-A72 (4x 1,5 GHz) |
GPU |
Broadcom VideoCore VI |
RAM |
Up to 8 GB LPDDR4 |
Wireless LAN |
2,4 GHz and 5 GHz IEEE 802.11b/g/n/ac wireless LAN |
Bluetooth |
Bluetooth 5.0, BLE |
Ethernet |
Gigabit Ethernet |
USB |
2x USB-A 3.0 2x USB-A 2.0 |
GPIO |
Standard 40-pin GPIO header (fully backwards-compatible with previous boards) |
Video |
2x micro-HDMI ports (up to 4Kp60 supported) 2-lane MIPI DSI port (display) 2-lane MIPI CSI port (camera) |
Audio |
4-pole stereo audio and composite video port |
Multimedia |
H.265 (4Kp60 decode) H.264 (1080p60 decode, 1080p30 encode) OpenGL ES, 3.0 graphics |
SD card |
microSD (for operating system and storage) |
Power |
5 V | 3 A (via USB-C) 5 V | 3 A (via GPIO) Power over Ethernet (PoE) enabled – (requires separate PoE HAT) |
